AirTAC GFR200-06 Filter Regulator (GFR20006F1)
The AirTAC AirTAC GFR200-06 Filter Regulator (GFR20006F1) is a genuine G-series filter regulator: water separation, 40 µm particulate filtration and balanced-type pressure regulation combined in a single body. It has PT1/8" ports, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi). It does not lubricate — add a GL lubricator, or order the GFC two-unit set, if downstream equipment needs oil.
- TypeFilter regulator
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFR200-06 Filter Regulator (GFR20006F1)
The AirTAC GFR20006F1 is a genuine AirTAC G-series filter regulator: one body that both filters the air and regulates downstream pressure. This 200-size unit has a PT1/8 port, the standard 40 um filter element and the default differential-pressure drain that clears condensate on pressure differential. Regulated output is set anywhere from 0.15 to 0.9 MPa (20-130 psi), and the embedded square gauge reads the setpoint on an MPa scale.
This is a genuine AirTAC part from the G series, which spans sizes 200 through 600 with increasing port size and flow. The family also offers a 5 um (W) element, manual or automatic drains, other gauge scales or no gauge, and G (BSPP) or NPT threads. Because published flow is given as curves rather than one number, ask us and we will confirm datasheet figures for your use.
AirTAC GFR200-06 Filter Regulator (GFR20006F1) Technical Specifications
| Model | AirTAC GFR200-06 Filter Regulator (GFR20006F1) |
|---|---|
| Series | GFR200 filter regulator |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Adjusting mechanism | Balanced type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). Air must not freeze in the unit. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFR200-06 Filter Regulator (GFR20006F1)
| GFR200 | G-series filter regulator, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Mounting bracket included. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, bracket, gauge, shape, scale, grade, thread, reflux — a blank position takes the default. Example: GFR300-08 is a 300 body, PT1/4", differential drain, standard type, bracket included, gauge fitted, 40 µm, PT thread, no reflux valve.
Size Class
- GFR200PT1/8" - PT1/4"
- GFR300PT1/4" - PT1/2"
- GFR400PT3/8" - PT1/2"
- GFR600PT3/4" - PT1"
A larger body carries a larger port and holds set pressure better as flow rises. AirTAC publishes flow only as curves, so size the body from your peak demand with headroom. The GFR600 uses an aluminium-alloy bowl; the 200, 300 and 400 bodies use PC.
| This model | GFR200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFR300 |
| Add lubrication | GFC200-06 (two-unit set) |
Where the AirTAC GFR200-06 Filter Regulator (GFR20006F1) Is Used
Process control valve actuation
Supplies filtered, regulated air to pneumatic positioners and actuators on a process line, with the MPa gauge matching the plant's standard pressure units.
Robotic gripper air circuit
Feeds a pick-and-place robot's gripper cylinders with clean 40 um-filtered air held at the exact setpoint read on the square MPa gauge.
Control panel air supply
Mounted at the air inlet of a machine control panel, this compact filter regulator conditions the supply to all panel-mounted pneumatic components.
Is the AirTAC GFR200-06 Filter Regulator (GFR20006F1) the Right Unit?
Choose the 200 size / 1/8 inch PT port for compact circuits; move to 300, 400 or 600 when flow demand grows. Keep the standard 40 um element for general actuation, or order 5 um (W) when downstream equipment needs finer filtration. The differential-pressure drain on this version is maintenance-light; manual (M) and automatic (A) drains are available if your duty cycle demands them.
This version carries the embedded square gauge with an MPa scale; psi (2) or bar (3) scales, or no gauge (N), are alternatives in the catalogue. PT is the standard thread, with G (BSPP) and NPT offered as order options. Flow appears in the catalogue as curves, not a single rating, so let us confirm sizing against your flow and pressure before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Thread PT, G (BSPP) or NPT
- ✓ Oil needed downstream? Use GFC instead
Installation & Maintenance Notes
- check Mount vertically, bowl down, following the airflow arrow.
- check One body does the filtering and the regulating — no separate regulator needed.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
The PC bowl must not be cleaned with solvents — wipe it with a dry cloth. Without the K option, air cannot flow back through the unit. A filter regulator adds no oil to the line.
AirTAC GFR200-06 Filter Regulator (GFR20006F1) FAQ
AirTAC publishes G-series flow capacity as pressure-drop curves, not as a single rated number, so we cannot quote a l/min or SCFM figure here. Give us your application's flow and pressure and we will confirm the datasheet figures for the GFR20006F1 on request.
The F1 suffix in the code specifies the square gauge face with an MPa (metric) scale, which is the standard configuration. If your plant works in psi or bar, order scale 2 or 3 in the same series; code N omits the gauge entirely. All versions are the same 200-size filter regulator with a PT1/8 port and 0.15-0.9 MPa (20-130 psi) adjustment range.
