AirTAC GFR200-06 Filter Regulator (GFR20006JC1)
The AirTAC AirTAC GFR200-06 Filter Regulator (GFR20006JC1) is a genuine G-series filter regulator: water separation, 40 µm particulate filtration and balanced-type pressure regulation combined in a single body. It has PT1/8" ports, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi). It does not lubricate — add a GL lubricator, or order the GFC two-unit set, if downstream equipment needs oil.
- TypeFilter regulator
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFR200-06 Filter Regulator (GFR20006JC1)
GFR20006JC1 is an AirTAC G-series filter regulator combining filtration and pressure regulation in one body. The J in the code means no mounting bracket is supplied, and C1 specifies the external round gauge with a MPa scale. This size 200 configuration has a PT1/8" port, the standard 40 um filter element and the standard differential-pressure drain on its polycarbonate bowl. Maximum inlet pressure is 1.0 MPa (145 psi), the regulated range with the differential-pressure drain is 0.15-0.9 MPa (20-130 psi), and operating temperature is -5 to 70 C (non-freezing).
This is a genuine AirTAC part. The GFR family spans sizes 200, 300, 400 and 600 with ports from 1/8" to 1", a choice of drains, 40 um or 5 um elements, embedded square or external round gauges with MPa/psi/bar scales, and G (BSPP) or NPT threads as catalogue options. Flow is published as curves rather than a single rated figure, so we confirm datasheet figures for your application on request.
AirTAC GFR200-06 Filter Regulator (GFR20006JC1) Technical Specifications
| Model | AirTAC GFR200-06 Filter Regulator (GFR20006JC1) |
|---|---|
| Series | GFR200 filter regulator |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Adjusting mechanism | Balanced type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). Air must not freeze in the unit. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFR200-06 Filter Regulator (GFR20006JC1)
| GFR200 | G-series filter regulator, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| J | Supplied without bracket. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, bracket, gauge, shape, scale, grade, thread, reflux — a blank position takes the default. Example: GFR300-08 is a 300 body, PT1/4", differential drain, standard type, bracket included, gauge fitted, 40 µm, PT thread, no reflux valve.
Size Class
- GFR200PT1/8" - PT1/4"
- GFR300PT1/4" - PT1/2"
- GFR400PT3/8" - PT1/2"
- GFR600PT3/4" - PT1"
A larger body carries a larger port and holds set pressure better as flow rises. AirTAC publishes flow only as curves, so size the body from your peak demand with headroom. The GFR600 uses an aluminium-alloy bowl; the 200, 300 and 400 bodies use PC.
| This model | GFR200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFR300 |
| Add lubrication | GFC200-06 (two-unit set) |
Where the AirTAC GFR200-06 Filter Regulator (GFR20006JC1) Is Used
Truck and trailer service points
Filtering and regulating air at a service drop feeding pneumatic test connections and small tools in a commercial vehicle workshop, mounted directly at the port without a bracket.
Control panel air entry
Conditioning compressed air at the pneumatic entry to a machine control panel, with the round MPa gauge mounted externally for easy reading against the panel layout.
Repair bay air prep
General air preparation at an equipment repair bay, filtering shop air to 40 um and setting a stable regulated pressure for air-driven repair tools and test setups.
Is the AirTAC GFR200-06 Filter Regulator (GFR20006JC1) the Right Unit?
Pick this J-coded variant when you do not want a mounting bracket - for direct connection at the port or where you supply your own fixing; order the bracket-included equivalent if panel mounting is needed. The round external gauge (C1) reads in MPa; square embedded gauges and psi or bar scales are alternatives in the same series. Size 200 is the smallest GFR step; move to 300, 400 or 600 for larger ports and more flow capacity. The 40 um element is the standard grade, with the 5 um W variant for finer filtration. The differential-pressure drain fitted here can be specified as automatic (A) or manual (M), which also shifts the low end of the regulated range to 0.05 MPa. Thread is PT as the standard, with G (BSPP) and NPT as catalogue options. Flow is published as curves, not a single rating, so ask us to confirm sizing before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Thread PT, G (BSPP) or NPT
- ✓ Oil needed downstream? Use GFC instead
Installation & Maintenance Notes
- check Mount vertically, bowl down, following the airflow arrow.
- check One body does the filtering and the regulating — no separate regulator needed.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
The PC bowl must not be cleaned with solvents — wipe it with a dry cloth. Without the K option, air cannot flow back through the unit. A filter regulator adds no oil to the line.
AirTAC GFR200-06 Filter Regulator (GFR20006JC1) FAQ
There is no single published rated flow figure for this series; AirTAC provides flow as characteristic curves. Give us your operating pressure and required downstream flow and we will confirm the datasheet curve figures for this model on request.
No. The J in the code means the bracket is omitted. If you need the unit fixed to a panel or frame, ask us for the same configuration in the bracket-included variant, GFR20006C1, before ordering.
