AirTAC GFR200-06 Filter Regulator (GFR20006JC1W)
The AirTAC AirTAC GFR200-06 Filter Regulator (GFR20006JC1W) is a genuine G-series filter regulator: water separation, 5 µm particulate filtration and balanced-type pressure regulation combined in a single body. It has PT1/8" ports, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi). It does not lubricate — add a GL lubricator, or order the GFC two-unit set, if downstream equipment needs oil.
- TypeFilter regulator
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFR200-06 Filter Regulator (GFR20006JC1W)
GFR20006JC1W is an AirTAC GFR-series filter regulator: filtration and pressure regulation in one body. This 200-size unit has a PT1/8 port, a differential-pressure drain bowl in polycarbonate, the W-code 5 um filter element for finer particulate removal, and an external round pressure gauge on an MPa scale. The J code means no mounting bracket is included, and no check valve is fitted. Maximum inlet pressure is 1.0 MPa (145 psi) and, with the differential-pressure drain, the regulator setpoint spans 0.15-0.9 MPa (20-130 psi).
It is a genuine AirTAC part for compressed air only, rated -5 to 70 C (non-freezing). The GFR line runs from 200 to 600 size with ports from 1/8 to 1 inch, PT, G or NPT threads, automatic, manual or differential-pressure drains, 40 um standard or 5 um (W) elements, round or square gauges on MPa, psi or bar scales, and bracket or no-bracket builds. Flow is published as curves rather than a single rating, so we confirm the datasheet figures for your application on request.
AirTAC GFR200-06 Filter Regulator (GFR20006JC1W) Technical Specifications
| Model | AirTAC GFR200-06 Filter Regulator (GFR20006JC1W) |
|---|---|
| Series | GFR200 filter regulator |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Adjusting mechanism | Balanced type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). Air must not freeze in the unit. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFR200-06 Filter Regulator (GFR20006JC1W)
| GFR200 | G-series filter regulator, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| J | Supplied without bracket. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, bracket, gauge, shape, scale, grade, thread, reflux — a blank position takes the default. Example: GFR300-08 is a 300 body, PT1/4", differential drain, standard type, bracket included, gauge fitted, 40 µm, PT thread, no reflux valve.
Size Class
- GFR200PT1/8" - PT1/4"
- GFR300PT1/4" - PT1/2"
- GFR400PT3/8" - PT1/2"
- GFR600PT3/4" - PT1"
A larger body carries a larger port and holds set pressure better as flow rises. AirTAC publishes flow only as curves, so size the body from your peak demand with headroom. The GFR600 uses an aluminium-alloy bowl; the 200, 300 and 400 bodies use PC.
| This model | GFR200 · PT1/8" · 5 µm |
|---|---|
| One size up | GFR300 |
| Add lubrication | GFC200-06 (two-unit set) |
Where the AirTAC GFR200-06 Filter Regulator (GFR20006JC1W) Is Used
Spray gun finishing bench
The 5 um element removes finer particles ahead of paint spray guns on a small finishing bench, while the regulator holds a steady gun supply pressure on the MPa gauge.
Pneumatic dosing station
Prepares and regulates air to a small dosing or filling head on a bottling or dispensing rig, where the finer 5 um grade helps protect the metering valve seat.
Air motor and agitator feed
Supplies filtered, regulated air to a small air motor or agitator on a mixing stand, with the round MPa gauge giving a repeatable speed-setting reference.
Is the AirTAC GFR200-06 Filter Regulator (GFR20006JC1W) the Right Unit?
The 200 size suits compact 1/8 inch point-of-use drops; move to 300, 400 or 600 for larger ports and more flow. The W suffix here selects the 5 um element instead of the 40 um standard - choose it when downstream valves or tools are sensitive to finer particles. Drain is the default differential-pressure type, and the gauge is the round (C) version on an MPa scale; F gives a square gauge and scales 2 or 3 give psi or bar. Threads can be ordered as G (BSPP) or T (NPT) instead of PT, and dropping the J code adds a bracket.
Flow for the GFR series is published as curves, not a single rated figure, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Thread PT, G (BSPP) or NPT
- ✓ Oil needed downstream? Use GFC instead
Installation & Maintenance Notes
- check Mount vertically, bowl down, following the airflow arrow.
- check One body does the filtering and the regulating — no separate regulator needed.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
The PC bowl must not be cleaned with solvents — wipe it with a dry cloth. Without the K option, air cannot flow back through the unit. A filter regulator adds no oil to the line.
AirTAC GFR200-06 Filter Regulator (GFR20006JC1W) FAQ
AirTAC publishes GFR flow data as curves rather than a single rated figure, so no single number is quoted here. Send us your application details and we will confirm the datasheet figures and check the 200 size and PT1/8 port against your flow requirement before you order.
W selects the 5 um filter element instead of the standard 40 um grade, for finer particulate removal ahead of sensitive equipment. Everything else decodes the usual way: 200 size, PT1/8 port, differential-pressure drain, standard regulator and a round gauge on an MPa scale, with no bracket in this J-code build.
