AirTAC GFR200-06 Filter Regulator (GFR20006JC1WK)
The AirTAC AirTAC GFR200-06 Filter Regulator (GFR20006JC1WK) is a genuine G-series filter regulator: water separation, 5 µm particulate filtration and balanced-type pressure regulation combined in a single body. It has PT1/8" ports, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi). It does not lubricate — add a GL lubricator, or order the GFC two-unit set, if downstream equipment needs oil.
- TypeFilter regulator
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFR200-06 Filter Regulator (GFR20006JC1WK)
GFR20006JC1WK is an AirTAC GFR-series filter regulator: filtration and pressure regulation in a single body. This 200-size unit carries a PT1/8 port, a differential-pressure drain bowl in polycarbonate, the W-code 5 um filter element, an external round pressure gauge on an MPa scale, and a fitted reverse (check) valve that permits reverse flow when the supply is removed. The J code means no mounting bracket is included. Maximum inlet pressure is 1.0 MPa (145 psi) and, with the differential-pressure drain, the regulator setpoint spans 0.15-0.9 MPa (20-130 psi).
It is a genuine AirTAC part for compressed air only, rated -5 to 70 C (non-freezing). The GFR line runs from 200 to 600 size with ports from 1/8 to 1 inch, PT, G or NPT threads, automatic, manual or differential-pressure drains, 40 um standard or 5 um (W) elements, round or square gauges on MPa, psi or bar scales, and bracket or no-bracket builds. Flow is published as curves rather than a single rating, so we confirm the datasheet figures for your application on request.
AirTAC GFR200-06 Filter Regulator (GFR20006JC1WK) Technical Specifications
| Model | AirTAC GFR200-06 Filter Regulator (GFR20006JC1WK) |
|---|---|
| Series | GFR200 filter regulator |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Adjusting mechanism | Balanced type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Fitted (reverse flow permitted) |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). Air must not freeze in the unit. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFR200-06 Filter Regulator (GFR20006JC1WK)
| GFR200 | G-series filter regulator, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| J | Supplied without bracket. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| K | Reverse-flow (reflux) valve fitted. |
Field order is size, port, drain, type, bracket, gauge, shape, scale, grade, thread, reflux — a blank position takes the default. Example: GFR300-08 is a 300 body, PT1/4", differential drain, standard type, bracket included, gauge fitted, 40 µm, PT thread, no reflux valve.
Size Class
- GFR200PT1/8" - PT1/4"
- GFR300PT1/4" - PT1/2"
- GFR400PT3/8" - PT1/2"
- GFR600PT3/4" - PT1"
A larger body carries a larger port and holds set pressure better as flow rises. AirTAC publishes flow only as curves, so size the body from your peak demand with headroom. The GFR600 uses an aluminium-alloy bowl; the 200, 300 and 400 bodies use PC.
| This model | GFR200 · PT1/8" · 5 µm |
|---|---|
| One size up | GFR300 |
| Add lubrication | GFC200-06 (two-unit set) |
Where the AirTAC GFR200-06 Filter Regulator (GFR20006JC1WK) Is Used
Small pneumatic press
Filters and regulates air to a compact pneumatic press; the check valve lets the cylinder circuit vent back through the unit when the main supply is isolated.
Gripper circuit with reverse flow
Feeds a robot gripper or clamp actuator where the 5 um element protects the small control valve and the fitted check valve permits reverse flow when supply is dropped.
Assembly bench tool drop
A compact supply point for air tools at a repair or assembly bench: 5 um filtration ahead of the tool and a set regulated pressure read on the round MPa gauge.
Is the AirTAC GFR200-06 Filter Regulator (GFR20006JC1WK) the Right Unit?
Choose the 200 size for a compact 1/8 inch point-of-use port; step to 300, 400 or 600 for larger ports and more flow. Here the W code gives the 5 um element instead of the 40 um standard, and the trailing K adds a check valve for reverse flow - drop it if your circuit does not need one. Drain is the default differential-pressure type, and the gauge is round (C) on an MPa scale; F gives a square gauge and scales 2 or 3 give psi or bar. Order G (BSPP) or T (NPT) threads instead of PT if needed, and drop the J code to include a bracket.
Flow for the GFR series is published as curves, not a single rated figure, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Thread PT, G (BSPP) or NPT
- ✓ Oil needed downstream? Use GFC instead
Installation & Maintenance Notes
- check Mount vertically, bowl down, following the airflow arrow.
- check One body does the filtering and the regulating — no separate regulator needed.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
The PC bowl must not be cleaned with solvents — wipe it with a dry cloth. The reflux valve permits reverse flow through the unit. A filter regulator adds no oil to the line.
AirTAC GFR200-06 Filter Regulator (GFR20006JC1WK) FAQ
AirTAC publishes flow for the GFR series as curves, not as a single rated figure, so we do not quote a number here. Share your application and we will confirm the datasheet figures and check the 200 size and PT1/8 port against your flow requirement before you order.
The trailing K fits a reverse (check) valve, so downstream air can flow back through the unit when supply pressure is removed - useful where a cylinder or actuator circuit must vent through the prep unit. If you do not need reverse flow, order the same unit without the K. Both share the 5 um element, PT1/8 port, differential-pressure drain and round MPa gauge.
