AirTAC GFR200-06 Filter Regulator (GFR20006JF1W)
The AirTAC AirTAC GFR200-06 Filter Regulator (GFR20006JF1W) is a genuine G-series filter regulator: water separation, 5 µm particulate filtration and balanced-type pressure regulation combined in a single body. It has PT1/8" ports, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi). It does not lubricate — add a GL lubricator, or order the GFC two-unit set, if downstream equipment needs oil.
- TypeFilter regulator
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFR200-06 Filter Regulator (GFR20006JF1W)
An AirTAC G-series filter regulator that cleans compressed air and holds downstream pressure in one compact body. This GFR20006JF1W is the 200 size with a 1/8 in PT port, a fine 5 um filter element (W code), differential-pressure drain and an embedded square gauge scaled in MPa. It comes without a mounting bracket (J). Maximum inlet pressure is 1.0 MPa (145 psi); the regulation range with differential-pressure drain is 0.15-0.9 MPa (20-130 psi); operating temperature is -5 to 70 C, and the 200-size bowl is polycarbonate (PC).
This is a genuine AirTAC part. The GFR family runs from size 200 to 600 with ports from 1/8 to 1 in, in G (BSPP) or NPT thread on request, with automatic, manual or differential-pressure drains, 40 um or 5 um (W) elements, MPa, psi or bar gauge scales, and an optional bracket. Flow is published as curves rather than a single rating, so we confirm datasheet and flow figures for your application on request.
AirTAC GFR200-06 Filter Regulator (GFR20006JF1W) Technical Specifications
| Model | AirTAC GFR200-06 Filter Regulator (GFR20006JF1W) |
|---|---|
| Series | GFR200 filter regulator |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Adjusting mechanism | Balanced type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). Air must not freeze in the unit. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFR200-06 Filter Regulator (GFR20006JF1W)
| GFR200 | G-series filter regulator, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| J | Supplied without bracket. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, bracket, gauge, shape, scale, grade, thread, reflux — a blank position takes the default. Example: GFR300-08 is a 300 body, PT1/4", differential drain, standard type, bracket included, gauge fitted, 40 µm, PT thread, no reflux valve.
Size Class
- GFR200PT1/8" - PT1/4"
- GFR300PT1/4" - PT1/2"
- GFR400PT3/8" - PT1/2"
- GFR600PT3/4" - PT1"
A larger body carries a larger port and holds set pressure better as flow rises. AirTAC publishes flow only as curves, so size the body from your peak demand with headroom. The GFR600 uses an aluminium-alloy bowl; the 200, 300 and 400 bodies use PC.
| This model | GFR200 · PT1/8" · 5 µm |
|---|---|
| One size up | GFR300 |
| Add lubrication | GFC200-06 (two-unit set) |
Where the AirTAC GFR200-06 Filter Regulator (GFR20006JF1W) Is Used
Spray-gun supply in a small paint booth
Filters and regulates air to spray guns in a small finishing booth, with the 5 um element helping protect the finish from particulate carry-over.
Analytical sample-handling panel
Conditions plant compressed air to 5 um and a set pressure before it reaches the pneumatic valves in an analytical sample-handling panel.
Instrumentation cabinet actuation
Supplies a regulated 1/8 in branch inside a control cabinet feeding small pilot valves and actuators, with the MPa gauge mounted in the door view.
Is the AirTAC GFR200-06 Filter Regulator (GFR20006JF1W) the Right Unit?
The 200 body with a 1/8 in PT port suits compact circuits and small-bore cylinders; step up to 300, 400 or 600 when the flow curve demands a larger port. Drain choices are differential-pressure (as here), automatic (A) or manual (M). This unit carries the 5 um (W) element instead of the 40 um standard, for finer protection of downstream components. The embedded square gauge can be ordered in MPa (1), psi (2) or bar (3) scale; J means no bracket, so order one separately if you need to mount the unit. Thread is PT as standard; G (BSPP) and NPT are catalogue options. Flow is published as curves, not a single rated figure, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Thread PT, G (BSPP) or NPT
- ✓ Oil needed downstream? Use GFC instead
Installation & Maintenance Notes
- check Mount vertically, bowl down, following the airflow arrow.
- check One body does the filtering and the regulating — no separate regulator needed.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
The PC bowl must not be cleaned with solvents — wipe it with a dry cloth. Without the K option, air cannot flow back through the unit. A filter regulator adds no oil to the line.
AirTAC GFR200-06 Filter Regulator (GFR20006JF1W) FAQ
AirTAC publishes G-series flow as curves, not a single rated figure, so there is no one rated flow number to quote. Tell us your application and we will confirm the datasheet flow curves and check whether this 200-size, 1/8 in unit is the right step before you order.
The W code swaps the standard 40 um element for a 5 um one, giving finer filtration for sensitive downstream devices such as pilot valves or spray equipment. Everything else in the code - 200 size, 1/8 in PT port, MPa square gauge, differential-pressure drain - stays the same.
