AirTAC GFR200-06 Filter Regulator (GFR20006JNK)
The AirTAC AirTAC GFR200-06 Filter Regulator (GFR20006JNK) is a genuine G-series filter regulator: water separation, 40 µm particulate filtration and balanced-type pressure regulation combined in a single body. It has PT1/8" ports, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi). It does not lubricate — add a GL lubricator, or order the GFC two-unit set, if downstream equipment needs oil.
- TypeFilter regulator
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeNot fitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFR200-06 Filter Regulator (GFR20006JNK)
GFR20006JNK is an AirTAC G-series filter regulator: filtration and pressure regulation in one body, for compressed air only, with a reverse (check) valve fitted (K). This 200-size unit has a PT1/8 port, the standard 40 um filter element, a differential-pressure drain and no gauge (N), and is supplied without a mounting bracket (J). The regulator adjusts from 0.15 to 0.9 MPa (20-130 psi), maximum inlet pressure is 1.0 MPa (145 psi), and the polycarbonate bowl suits -5 to 70 C service.
It is a genuine AirTAC part. The G-series runs from size 200 to 600 with ports from 1/8 to 1 inch, PT, G (BSPP) or NPT threads, differential-pressure, automatic or manual drains, 40 um or 5 um elements, and gauge or no-gauge variants; 200-400 bowls are polycarbonate, 600 is aluminium alloy. Flow is published as curves rather than a single rated figure, so we confirm datasheet values on request.
AirTAC GFR200-06 Filter Regulator (GFR20006JNK) Technical Specifications
| Model | AirTAC GFR200-06 Filter Regulator (GFR20006JNK) |
|---|---|
| Series | GFR200 filter regulator |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Adjusting mechanism | Balanced type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Not fitted |
| Reflux valve | Fitted (reverse flow permitted) |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). Air must not freeze in the unit. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFR200-06 Filter Regulator (GFR20006JNK)
| GFR200 | G-series filter regulator, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| J | Supplied without bracket. |
| N | No pressure gauge (N). |
| (blank) | Gauge shape: Factory standard. C is round, F is square. |
| (blank) | Gauge scale: Factory standard. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| K | Reverse-flow (reflux) valve fitted. |
Field order is size, port, drain, type, bracket, gauge, shape, scale, grade, thread, reflux — a blank position takes the default. Example: GFR300-08 is a 300 body, PT1/4", differential drain, standard type, bracket included, gauge fitted, 40 µm, PT thread, no reflux valve.
Size Class
- GFR200PT1/8" - PT1/4"
- GFR300PT1/4" - PT1/2"
- GFR400PT3/8" - PT1/2"
- GFR600PT3/4" - PT1"
A larger body carries a larger port and holds set pressure better as flow rises. AirTAC publishes flow only as curves, so size the body from your peak demand with headroom. The GFR600 uses an aluminium-alloy bowl; the 200, 300 and 400 bodies use PC.
| This model | GFR200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFR300 |
| Add lubrication | GFC200-06 (two-unit set) |
Where the AirTAC GFR200-06 Filter Regulator (GFR20006JNK) Is Used
Manifold feed with hold-up
Feeds a solenoid valve manifold where downstream pressure should persist through short upstream dips; the fitted reverse valve blocks backflow toward the regulator.
Press air assist
Regulates assist and ejection air on a small press or forming station, with the standard 40 um element matched to ordinary plant air.
Clamp-hold circuit
Serves clamp circuits on assembly fixtures where air must not drain back through the supply leg; the K suffix reverse valve helps retain line-side pressure.
Is the AirTAC GFR200-06 Filter Regulator (GFR20006JNK) the Right Unit?
Pick this code when you want the plain 200-size, PT1/8, 40 um build plus the K suffix reverse valve, which allows flow from the regulator to the line while blocking reverse flow toward the unit. No gauge is fitted and no bracket is included; both have alternative order codes. Thread is PT as standard, with G (BSPP) and NPT as catalogue options, and the differential-pressure drain needs no daily attention. Because G-series flow is published as curves rather than a single rating, ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Thread PT, G (BSPP) or NPT
- ✓ Oil needed downstream? Use GFC instead
Installation & Maintenance Notes
- check Mount vertically, bowl down, following the airflow arrow.
- check One body does the filtering and the regulating — no separate regulator needed.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
The PC bowl must not be cleaned with solvents — wipe it with a dry cloth. The reflux valve permits reverse flow through the unit. A filter regulator adds no oil to the line.
AirTAC GFR200-06 Filter Regulator (GFR20006JNK) FAQ
AirTAC publishes G-series flow as performance curves rather than a single rated figure, so we do not state a rated flow number here. Give us your inlet pressure, set pressure and air demand, and we will confirm sizing from the datasheet on request before you order.
K fits a reverse (check) valve at the unit: air passes from the regulator to the line while reverse flow is blocked, which suits circuits where downstream pressure should be retained if upstream supply dips. The rest of the decode is unchanged: PT1/8 port, 40 um element, no gauge, differential-pressure drain.
