Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X15S
The AirTAC Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X15S is a genuine HLH slide-table cylinder, 10 mm bore: a double-acting dual-rod air cylinder integrated with a miniature linear roller-ball guide so the table travels straight with high rigidity and low deflection. It delivers about 31.4 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideminiature linear roller-ball guide
- Bore10 mm
- Push thrust @0.5 MPa31.4 N
- Operating pressure0.2 - 0.7 MPa (29 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X15S
The AirTAC HLH10X15S is a double-acting dual-rod slide-table cylinder with an integrated miniature linear roller-ball guide. At a 10 mm bore and 15 mm stroke, it provides the best straightness in the HL family through precision assembly, with the dual rods doubling thrust and a floating joint protecting the rods from side torque. The body mounts in four directions and offers three port groups for flexible installation.
This is a genuine AirTAC part with a standard magnet for position sensing using CMSH, DMSH, or EMSH sensor switches in the body slots. We confirm the exact thrust, dimensions, and allowable load/moment values from the published datasheet or on-page specification table on request.
Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X15S Technical Specifications
| Model | Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X15S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLH (miniature linear roller-ball guide) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 31.4 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 0.7 MPa (29 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Choose the 10 mm bore for moderate thrust in a compact miniature package; larger bores (16/20) in the HLH range give higher push. The HLH miniature roller-ball guide delivers superior straightness through precision assembly versus the HLS cross-roller or HLQ ball-bearing alternatives. The 15 mm stroke should be within the bore's datasheet table; select PT, G, or NPT thread to match your fittings. We can confirm allowable load, moment, and deflection curves from the published tables for your sizing.
Applications
Gripper Traverse Slide
Moves a small gripper laterally with excellent straightness for precise part pickup and placement in a compact assembly cell.
Small-Parts Transfer
Transfers miniature components between stations with straight, repeatable 15 mm travel and minimal deflection under the workpiece.
Assembly Stage Slide
Indexes a sub-assembly into position under an assembly head where the compact 15 mm stroke and four-way mounting fit tight spaces.
FAQ
Is the magnet standard on the HLH10X15S?
Yes, the S in the code means a magnet is fitted as standard. The magnetic switch slots accept CMSH, DMSH, or EMSH sensor switches for position detection.
How is allowable load confirmed for this model?
Allowable load, moment, and deflection are published as tables and curves in the datasheet. We confirm these values for your specific mounting and load condition on request.
