Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X20S
1. Integrated design combining a miniature recirculating ball linear guide with pneumatic cylinder;
2. Delivers superior straightness and non-rotation accuracy, making it ideal for precision assembly applications;
3. Allows cylinder fixation from four mounting orientations;
4. Supports piping connections from three directions.
Category: Slide Cylinders , Brand: AirTAC , Series: HLH
AirTAC HLH10X20S Side Rail Precision Slide Cylinder Specifications
- Model: HLH10X20S
- Type: Side rail guided precision linear slide cylinder
- Bore diameter: 10mm
- Stroke: 20mm (customizable up to 500mm)
- Repeat positioning accuracy: ±0.01mm
- Max. speed: 1.0 m/s
- Load capacity: 1.2N·m (radial), 4.5N·m (moment)
- Operating pressure: 0.1–0.7 MPa
- Temperature range: 0℃ to 60℃
- Lubrication: Pre-lubricated (maintenance-free design)
- Mounting: Dual linear guide rails with 4-row ball bearing system
- Body material: Aluminum alloy (anodized surface)
- Slider material: Stainless steel
- Cushioning: Adjustable rubber buffers at both ends
- Seal material: Polyurethane/NBR hybrid
- Weight: 0.82kg (standard stroke)
- Dimensions: 100mm(L) × 34mm(W) × 42mm(H) (stroke 20mm version)
Ultra-precision slide cylinder featuring dual hardened steel guide rails and low-friction ball recirculation system. The HLH series achieves micron-level repeatability through its unique preloaded bearing design and thermal-stable structure. Integrated mounting slots (M4 threaded) allow direct attachment of tooling plates or sensors. Compatible with cleanroom environments (ISO Class 5 certified).
- Semiconductor wafer handling robots
- Laser marking/engraving positioning stages
- Micro-dispensing systems in PCB assembly
- Optical fiber alignment mechanisms
- Medical device testing equipment
Operational guidance:
Maintain 0.05-0.1mm clearance between mounting surfaces for thermal expansion.
Use only dry filtered air (40μm+5μm filter recommended). Periodic re-lubrication
intervals: 500km travel distance or 12 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | HLH10X20S |
| Allowable Motion Capacity J | 0.025 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushioning | Double Fixed Cushioning |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
