Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X25S
1. Integrated design combining a miniature recirculating ball linear guide with pneumatic cylinder;
2. Delivers superior straightness and non-rotation accuracy, making it ideal for precision assembly applications;
3. Allows cylinder fixation from four mounting orientations;
4. Supports piping connections from three directions.
Category: Slide Cylinders , Brand: AirTAC , Series: HLH
AirTAC HLH Series Side Rail Precision Slide Cylinder HLH10X25S Specifications
- Model: HLH10X25S
- Series: HLH (High Precision Side Rail Type)
- Bore size: 10mm
- Stroke: 25mm (±0.5mm tolerance)
- Max speed: 0.5-1.2 m/s (lubricated condition)
- Max thrust: 30N at 0.63MPa
- Repeat positioning accuracy: ±0.01mm
- Operating pressure: 0.1-0.7 MPa
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubed with SNS Grease (relubrication every 500km travel)
- Lead: 5mm/rev
- Guide rail type: Dual linear shaft structure
- Seal material: Special polyurethane + NBR combination
- Buffer type: Adjustable rubber cushion
- Mounting orientation: Horizontal or vertical (axial load only)
- Weight: 0.48kg (excluding accessories)
- Dimensions: 140mm(L) × 34mm(W) × 34mm(H) (retracted position)
Ultra-compact linear motion solution with hardened steel guide shafts (HRC60+) and aluminum alloy body. Features zero-backlash ball bearing slides and integrated dust-resistant wipers. Requires clean compressed air (ISO 8573-1:2010 Class 2-4-2) with 5-10μm filtration. Delivers smooth motion with ≤0.5μm surface roughness on critical components.
- Precision alignment stages in semiconductor FOUP handling
- Linear actuators for optical lens coating machines
- PCB inspection probe positioning systems
- Medical device assembly with cleanroom requirements
- 3D printing extruder head linear guides
Installation note:
Maintain 0.02mm/m alignment tolerance during mounting. Apply initial run-in at 50% speed for 200 cycles.
Avoid side loads exceeding 5N. Use torque limiter when tightening mounting screws (max 1.2N·m).
| Property | Property Value |
|---|---|
| sku | HLH10X25S |
| Allowable Motion Capacity J | 0.025 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushioning | Double Fixed Cushioning |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
