Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X30S
The AirTAC Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X30S is a genuine HLH slide-table cylinder, 10 mm bore: a double-acting dual-rod air cylinder integrated with a miniature linear roller-ball guide so the table travels straight with high rigidity and low deflection. It delivers about 31.4 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideminiature linear roller-ball guide
- Bore10 mm
- Push thrust @0.5 MPa31.4 N
- Operating pressure0.2 - 0.7 MPa (29 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X30S
The AirTAC HLH10X30S is a double-acting dual-rod slide table cylinder that integrates an air cylinder with a precision miniature linear roller-ball guide. This guide type provides the best straightness and precision assembly, ensuring precise guided travel with low deflection. The dual rod doubles the thrust, and a floating joint spares the rod from side torque. For a 10mm bore and 30mm stroke, this model delivers moderate thrust in a compact footprint.
This is a genuine AirTAC part. A magnet is standard for position sensing, compatible with CMSH, DMSH, and EMSH sensor switches. We confirm the exact thrust, dimensions, and load-moment values from the datasheet or on-page table on request.
Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X30S Technical Specifications
| Model | Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X30S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLH (miniature linear roller-ball guide) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 31.4 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 0.7 MPa (29 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Choosing the right bore is key for thrust requirements; a 10mm bore offers a solid balance of compact size and moderate push force. The HLH series is selected when the miniature roller-ball guide's straightness and three port groups are needed for flexible mounting in four directions. Stroke 30mm is within the bore's standard table. Since HLH models do not carry an adjuster code, bumper cushion is standard. We route load/moment sizing to the published tables and curves on request.
Applications
Pick-and-Place
Precise guided transfer of small components in a pick-and-place station.
Assembly Stage
Low-deflection linear movement for accurate part alignment during automated assembly.
Gripper Traverse
Smooth, straight-line actuation to position grippers exactly in robotic handling.
FAQ
Is the magnet optional on the HLH10X30S?
No, the S in the model code indicates the magnet is standard and cannot be declined. It is compatible with CMSH, DMSH, and EMSH sensor switches.
What is the maximum operating pressure for this 10mm bore slide table?
The maximum working pressure is 0.7 MPa. The operating pressure range for a 10mm bore is 0.2 to 0.7 MPa (29 to 100 psi).
