Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X40S
1. Integrated design combining a miniature recirculating ball linear guide with pneumatic cylinder;
2. Delivers superior straightness and non-rotation accuracy, making it ideal for precision assembly applications;
3. Allows cylinder fixation from four mounting orientations;
4. Supports piping connections from three directions.
Category: Slide Cylinders , Brand: AirTAC , Series: HLH
AirTAC HLH10X40S Side Rail Precision Slide Cylinder Specifications
- Model: HLH10X40S
- Structure: Side rail guided cylinder with integrated linear guide
- Bore size: Ø10mm
- Stroke: 40mm (standard), customizable up to 500mm
- Repeat positioning accuracy: ±0.01mm
- Max. speed: 1.5m/s (with cushioning)
- Max. thrust: 31N at 0.5MPa
- Operating pressure: 0.05-0.7MPa
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body, stainless steel guide rails
- Seal type: NBR seals (FKM available on request)
- Mounting: Dual-side mounting holes (M4×0.7, depth 6mm)
- Guide type: High-precision ball bearing linear guide
- Lubrication: Pre-lubricated (Grease: ISO VG10-32)
- Cushioning: Adjustable rubber buffers both ends
- Weight: 0.82kg (excluding accessories)
- Dimensions: 200mm(L) × 60mm(W) × 50mm(H) (full extension)
High-rigidity slide cylinder combining pneumatic actuation with precision linear guidance, featuring zero backlash and minimal deflection (≤0.05mm at max load). The dual-shaft design with hardened rails ensures smooth movement under moment loads. Includes built-in T-slot for sensor mounting and optional magnetic piston for position feedback.
- Precision alignment stages in semiconductor wafer handling
- Vertical Z-axis positioning in PCB drilling machines
- Component insertion mechanisms in micro-assembly lines
- Lens adjustment systems in optical equipment
- Test probe positioning for electronic component validation
Installation note:
Maintain parallelism within 0.1mm/m between mounting surfaces. Use torque-controlled driver (1.2N·m max) for rail fasteners.
For vertical installations, implement anti-drop mechanism (optional brake unit available).
- Air quality: ISO 8573-1 Class 3.4.2 (40μm filtration)
- Relubrication interval: 2,000km travel or 6 months
- Max lateral load: 15N (perpendicular to rod axis)
- Max moment load: 1.5N·m (all directions)
| Property | Property Value |
|---|---|
| sku | HLH10X40S |
| Allowable Motion Capacity J | 0.025 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushioning | Double Fixed Cushioning |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
