Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X45S
The AirTAC Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X45S is a genuine HLH slide-table cylinder, 10 mm bore: a double-acting dual-rod air cylinder integrated with a miniature linear roller-ball guide so the table travels straight with high rigidity and low deflection. It delivers about 31.4 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideminiature linear roller-ball guide
- Bore10 mm
- Push thrust @0.5 MPa31.4 N
- Operating pressure0.2 - 0.7 MPa (29 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X45S
A slide-table cylinder integrates an air cylinder with a linear guide so the moving table travels straight. The HLH10X45S uses a precision miniature linear roller-ball integrated guide offering the best straightness and precision assembly for moderate thrust applications. The dual-rod double-acting design doubles the thrust, while a floating joint spares the rod from side torque.
This is a genuine AirTAC part with a standard magnet and magnetic-switch slots on the body for CMSH, DMSH, and EMSH sensors. We confirm thrust, dimensions, and allowable load-moment from the datasheet or on-page table on request.
Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X45S Technical Specifications
| Model | Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X45S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLH (miniature linear roller-ball guide) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 31.4 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 0.7 MPa (29 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 10 offers moderate push; select the 45mm stroke from the HLH bore's table to match your travel needs. The HLH sub-family provides best straightness and mounts in 4 directions with three port groups. Route load and moment sizing to us, as these are published as tables and deflection curves.
Applications
Pick-and-Place
Precise guided travel for small electronic component pick-and-place stations.
Small-Parts Transfer
Transfers small parts between conveyor lines with minimal deflection.
Gripper Traverse
Moves gripper jaws straight along an assembly line without side torque.
FAQ
Is the magnet standard and what sensors are used?
Yes, the magnet is standard on all HLH models. Compatible sensors include AirTAC CMSH, DMSH, and EMSH series that fit the magnetic-switch slots on the body.
What is the maximum operating pressure for the HLH10?
For the 10mm bore, the operating pressure is 0.2-0.7 MPa (29-100 psi). Maximum working pressure must never exceed 0.7 MPa. Meter-out speed control should keep travel between 50-500 mm/s.
