Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X50S
1. Integrated design combining a miniature recirculating ball linear guide with pneumatic cylinder;
2. Delivers superior straightness and non-rotation accuracy, making it ideal for precision assembly applications;
3. Allows cylinder fixation from four mounting orientations;
4. Supports piping connections from three directions.
Category: Slide Cylinders , Brand: AirTAC , Series: HLH
AirTAC HLH10X50S Side Rail Type Precision Slide Cylinder Specifications
- Model: HLH10X50S
- Type: Side rail guided linear actuator with integrated guide mechanism
- Stroke: 50mm (±0.5mm tolerance)
- Max load capacity: 2.5N·m (lateral), 6.5N·m (longitudinal)
- Repeat positioning accuracy: ±0.01mm
- Operating pressure: 0.05-0.7 MPa
- Max speed: 500mm/s (pneumatic), 1000mm/s (mechanical)
- Buffer type: Adjustable rubber cushion
- Rail type: Dual linear guideways with 4-row ball bearing system
- Seal material: Polyurethane (PU) with wear-resistant coating
- Temperature range: -10℃ to 80℃
- Mounting orientation: Any direction (horizontal/vertical)
- Weight: 0.9kg (excluding accessories)
- Dimensions: 160mm(L) × 42mm(W) × 34mm(H) (compact design with 10mm rail width)
- Rod end types: Optional clevis, flange, or threaded end
- Lubrication: Pre-lubricated (maintenance-free for 2000km travel)
High-rigidity slide cylinder featuring ultra-precise linear motion through dual linear guides and optimized ball recirculation system. The anodized aluminum construction ensures corrosion resistance while maintaining minimal friction coefficient (μ<0.003). Integrated dust seals (IP54 equivalent) protect internal mechanisms from particulate contamination.
- Precision alignment stages in optical equipment assembly
- Z-axis drives for CNC measuring instruments
- Wafer handling robots in semiconductor manufacturing
- High-speed pick-and-place mechanisms
- Medical device assembly systems requiring ISO Class 5 cleanliness
Installation note:
Use M4x8 mounting screws (ISO 4762) with 0.7Nm torque limit. For vertical installations,
maintain 0.02-0.05mm clearance between rail and base plate using precision shims.
Apply ISO VG32 hydraulic oil if operated below -5℃.
| Property | Property Value |
|---|---|
| sku | HLH10X50S |
| Allowable Motion Capacity J | 0.025 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushioning | Double Fixed Cushioning |
| Bore Diameter | <10mm> |
| Stroke | <50mm> |
