Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X5S
The AirTAC Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X5S is a genuine HLH slide-table cylinder, 10 mm bore: a double-acting dual-rod air cylinder integrated with a miniature linear roller-ball guide so the table travels straight with high rigidity and low deflection. It delivers about 31.4 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideminiature linear roller-ball guide
- Bore10 mm
- Push thrust @0.5 MPa31.4 N
- Operating pressure0.2 - 0.7 MPa (29 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X5S
The AirTAC HLH10X5S is a double-acting dual-rod slide-table cylinder that integrates an air cylinder with a precision miniature linear roller-ball guide. The 10 mm bore and 5 mm stroke deliver light, precise thrust for short-travel positioning, while the dual rods double the push force and a floating joint protects the rods from side torque. The roller-ball guide provides excellent straightness and rigidity in a compact body.
This is a genuine AirTAC part with a standard sintered NdFeB magnet for position sensing; compatible sensor switches are CMSH, DMSH, and EMSH series, fitting the magnetic-switch slots on the cylinder body. We confirm exact thrust, dimensions, allowable load, and moment values from the manufacturer datasheet or on-page specification table on request.
Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X5S Technical Specifications
| Model | Airtac HLH Side Rail Type Precision Slide Cylinder HLH10X5S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLH (miniature linear roller-ball guide) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 31.4 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 0.7 MPa (29 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
The 10 mm bore suits applications needing light thrust and very compact footprint. Choose the HLH sub-family when you need the best guiding straightness and precision-assembly quality that the integrated miniature roller-ball guide provides, along with the ability to mount the body in four directions and use three port groups for flexible piping. Stroke must fall within the published range for the HLH10 bore.
No adjuster or shock-absorber option is available on the HLH series; cushioning is by bumper. Thread standard is PT (parallel pipe thread). For allowable load, moment, and kinetic energy sizing, route the figures to us so we can confirm against the published Wmax, Emax, and moment tables and deflection curves.
Applications
Precision Pick-and-Place
Short 5 mm stroke with roller-ball guide straightness positions small electronic components with minimal deflection during pick-and-place cycles.
Gripper Traverse
Compact 10 mm bore dual-rod slide moves a small gripper laterally between stations with precise repeatability on a precision-guided table.
Assembly Stage Stop
The low-profile roller-ball guided slide acts as a short-stroke positioning stop or pusher on a precision assembly fixture.
FAQ
Is the magnet standard on the HLH10X5S, and which sensors work with it?
Yes, the magnet is standard on every HLH series cylinder; it is not an optional add-on. Compatible magnetic sensor switches are AirTAC CMSH, DMSH, and EMSH series, which slot into the dedicated magnetic-switch grooves on the cylinder body.
What is the maximum operating pressure for this model?
The maximum working pressure is 0.7 MPa (100 psi). For the 10 mm bore the operating range is 0.2 to 0.7 MPa (29 to 100 psi). Proof pressure is 1.2 MPa (175 psi). Meter-out speed control keeps travel within 50 to 500 mm/s.
