Airtac HLH Side Rail Type Precision Slide Cylinder HLH16X35S
The AirTAC Airtac HLH Side Rail Type Precision Slide Cylinder HLH16X35S is a genuine HLH slide-table cylinder, 16 mm bore: a double-acting dual-rod air cylinder integrated with a miniature linear roller-ball guide so the table travels straight with high rigidity and low deflection. It delivers about 80.4 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideminiature linear roller-ball guide
- Bore16 mm
- Push thrust @0.5 MPa80.4 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLH Side Rail Type Precision Slide Cylinder HLH16X35S
A slide-table cylinder combines an air cylinder with a linear guide so the moving table moves along a precise straight path. The AirTAC HLH16X35S is a double-acting dual-rod slide table using a precision miniature linear roller-ball integrated guide that provides outstanding straightness and precision assembly. Dual rods double the thrust versus a single-rod unit, while a floating joint spares the rods from side torque. At 16 mm bore and 35 mm stroke, this model delivers moderate thrust for compact guided-motion applications. The HLH series supports four mounting directions and three port groups for versatile installation.
This is a genuine AirTAC part. Every unit ships with a sintered NdFeB magnet as standard, and the body has magnetic-switch slots that accept AirTAC CMSH, DMSH, and EMSH sensor switches. We verify the exact thrust, dimensions, allowable load, and moment figures from the AirTAC datasheet or on-page specification table on request.
Airtac HLH Side Rail Type Precision Slide Cylinder HLH16X35S Technical Specifications
| Model | Airtac HLH Side Rail Type Precision Slide Cylinder HLH16X35S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLH (miniature linear roller-ball guide) |
| Bore | 16 mm |
| Push thrust @0.5 MPa | 80.4 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Select the HLH sub-family when straightness and precision assembly matter more than raw rigidity. The 16 mm bore gives moderate thrust for small to mid-range guided loads; step up to bore 20 if your application needs higher push force. The 35 mm stroke must be within the HLH bore-16 range shown in the AirTAC catalog. HLH has no adjuster or shock-absorber option; cushioning is via a TPU bumper at each end. Thread is PT as standard; request G or NPT thread if needed. We confirm allowable load, moment, and deflection from published datasheet tables and curves before you order.
Applications
Small-Parts Pick-and-Place
Roller-ball precision picks and places micro-mechanical parts across a 35 mm stroke with repeatable positioning and minimal deflection.
Transfer Gate Slide
Dual-rod stability gates small product between conveyor lanes in a 16 mm bore compact form factor with three port-group options for tight layouts.
Compact Assembly Stage
Four-direction mounting integrates the HLH16 into a multi-axis assembly fixture where a 35 mm stroke drives a pressing or alignment operation.
FAQ
Does the HLH16X35S come with a magnet, or is it an option?
The magnet is standard on every HLH unit; S in the model code confirms a magnet is fitted. You cannot order this model without a magnet. The body has slots for AirTAC CMSH, DMSH, and EMSH sensor switches, which you add as needed for position detection.
Can I use a shock absorber or adjustable stopper on the HLH?
No. The HLH sub-family has no adjuster or shock-absorber option. Cushioning is provided by a TPU bumper at each end of the stroke. If you need adjustable rubber stoppers or shock absorbers, choose the HLS or HLQ sub-families, which carry A and B adjuster codes. HLH relies on its bumper cushion and precision roller-ball guide for end-of-stroke deceleration.
