Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X10S
The AirTAC Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X10S is a genuine HLH slide-table cylinder, 6 mm bore: a double-acting dual-rod air cylinder integrated with a miniature linear roller-ball guide so the table travels straight with high rigidity and low deflection. It delivers about 11.3 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideminiature linear roller-ball guide
- Bore6 mm
- Push thrust @0.5 MPa11.3 N
- Operating pressure0.2 - 0.7 MPa (29 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X10S
The HLH6X10S is a double-acting dual-rod slide-table cylinder with a precision miniature linear roller-ball integrated guide. The 6 mm bore with a 10 mm stroke provides light thrust in a very compact footprint, while the dual-rod design doubles the output force and the floating joint protects the rods from side torque. The roller-ball guide delivers exceptional straightness and precision assembly, and the body mounts in four directions with three available port groups.
This is a genuine AirTAC part with a standard magnet fitted. Magnetic-switch slots on the body accept CMSH, DMSH, or EMSH sensor switches. We confirm the exact thrust, dimensions, allowable load, and moment values from the datasheet or the on-page spec table on request.
Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X10S Technical Specifications
| Model | Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X10S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLH (miniature linear roller-ball guide) |
| Bore | 6 mm |
| Push thrust @0.5 MPa | 11.3 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 0.7 MPa (29 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
The 6 mm bore is the smallest in the HLH range, suited to light-thrust applications where space is at a premium. Choose HLH when your application needs the superior straightness and precision-assembly quality of the miniature roller-ball guide rather than the cross-roller HLS or ball-bearing HLQ alternatives. The 10 mm stroke is a short indexing move within the bore-6 range; confirm the maximum available stroke from the datasheet. Thread is PT (BSPT); G and NPT variants exist. Route load and moment sizing to us for confirmation against published tables and deflection curves.
Applications
Miniature Clamp Stage
Drives a 10 mm clamping finger against a small electronic component, the compact bore-6 body fitting in tight fixture spaces.
Micro-Part Shuttle
Shuttles a tiny part 10 mm between two micro-nests in a pick-and-place cell with the roller-ball guide ensuring precise straight travel.
Sensor Positioning Stop
Indexes a proximity sensor 10 mm into a reading position, four-direction mounting allowing flexible integration on a compact bracket.
FAQ
What thrust can the HLH6X10S produce, and how does bore size affect it?
The 6 mm bore provides light thrust suitable for small-part handling and positioning. A larger bore (10, 16, or 20 mm) delivers progressively higher thrust. The exact thrust figure for this model is shown in the on-page spec table or datasheet; we confirm it on request so you size correctly without guessing.
What operating pressure range applies to the HLH6X10S?
For the 6 mm bore, operating pressure is 0.2-0.7 MPa (29-100 psi). Maximum working pressure is 0.7 MPa (100 psi), never higher. Proof pressure is 1.2 MPa (175 psi). Keep speed between 50 and 500 mm/s using meter-out flow control.
