Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X15S
The AirTAC Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X15S is a genuine HLH slide-table cylinder, 6 mm bore: a double-acting dual-rod air cylinder integrated with a miniature linear roller-ball guide so the table travels straight with high rigidity and low deflection. It delivers about 11.3 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideminiature linear roller-ball guide
- Bore6 mm
- Push thrust @0.5 MPa11.3 N
- Operating pressure0.2 - 0.7 MPa (29 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X15S
The AirTAC HLH6X15S is a double-acting, dual-rod slide-table cylinder that integrates an air cylinder with a precision miniature linear roller-ball guide. This design provides best straightness and precision assembly, guiding the moving table straight while the dual rod doubles the thrust for this 6mm bore. A floating joint spares the rod from side torque, and the body mounts in four directions.
As a genuine AirTAC part, it includes a standard magnet for position sensing with CMSH, DMSH or EMSH sensor switches fitted into the body slots. We confirm the exact thrust, dimensions, load and moment ratings from the datasheet or on-page table on request.
Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X15S Technical Specifications
| Model | Airtac HLH Side Rail Type Precision Slide Cylinder HLH6X15S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLH (miniature linear roller-ball guide) |
| Bore | 6 mm |
| Push thrust @0.5 MPa | 11.3 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 0.7 MPa (29 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Selecting this 6mm bore provides light thrust suitable for compact tasks; choose a larger bore for more push. The HLH precision miniature roller-ball guide offers the best straightness and three port groups for flexible routing, making it ideal where precision assembly is required. Pick the 15mm stroke length within the bore's table for your travel needs, and confirm the thread. For allowable load, moment and kinetic energy, route the sizing to us; these are published as tables and curves.
Applications
Precision Pick-and-Place
Handles small electronic components with exact straightness using the integrated roller-ball guide.
Assembly Stage Traverse
Positions parts accurately on an assembly line with low deflection and four-way mounting flexibility.
Small Parts Transfer
Moves lightweight workpieces smoothly between stations using dual-rod thrust and a floating joint.
FAQ
What is the advantage of the HLH guide type?
The HLH series uses a precision miniature linear roller-ball integrated guide, providing the best straightness and precision assembly, with three port groups and four-way mounting.
What is the maximum operating pressure for this 6mm bore cylinder?
The maximum working pressure is 0.7 MPa, with an operating pressure range of 0.2-0.7 MPa (29-100 psi) for the 6mm bore size. We confirm load and moment ratings from the datasheet.
