Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X100SAS
The AirTAC Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X100SAS is a genuine HLQ slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X100SAS
The HLQ12X100SAS is a double-acting, dual-rod slide table cylinder with a 12 mm bore, 100 mm stroke and an integrated ball-bearing linear guide. The ball-bearing guide gives the series its anti-rust, dust-proof qualities and keeps the table travelling straight with low deflection over the full stroke. The dual-rod construction doubles the thrust delivered to the table, and a floating joint isolates the rod from side torque introduced by the tooling.
This genuine AirTAC model has a position magnet as standard equipment, read by CMSH, DMSH or EMSH switches seated in the slots on the body. The AS adjuster fits an adjustable rubber stopper on the extension side only, cushioning the table as it reaches the extended end. Thrust, overall dimensions and allowable load/moment data for this exact model are in the on-page spec table and datasheet; we will confirm any figure on request.
Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X100SAS Technical Specifications
| Model | Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X100SAS |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQ (ball-bearing guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 provides moderate thrust - move to a 16, 20 or 25 mm bore in the series if you need more push at the same pressure. HLQ suits applications that value an anti-rust, dust-proof ball-bearing guide; choose HLS if cross-roller rigidity and load capacity dominate, HLH for best straightness in a miniature roller-ball guide, or HLF where body height is tight. Check that 100 mm is a listed stroke for this bore.
The AS suffix here means an adjustable rubber stopper on the extension side; use SA for cushioning at both ends or AF for retraction only. This model has PT threads. For load and moment sizing, which AirTAC publishes as tables and curves rather than single numbers, send us your application details and we will size it from the datasheet.
Applications
Eject to outfeed
Pushes finished small parts off a nest to an outfeed bin, with the extension-side rubber stopper settling the table softly at the eject position.
Multi-station indexing slide
Carries a small carrier plate between two stations; the ball-bearing guide keeps travel parallel so parts present consistently.
Alignment push station
Squares parts against a fence before an operation; low deflection of the guided table keeps the push face perpendicular to the fence.
FAQ
Do I need to order a magnet or switches separately?
The magnet is fitted as standard on every HLQ slide table, so no magnet option is needed. For position detection, order CMSH, DMSH or EMSH sensor switches, which mount in the slots on the cylinder body.
What operating conditions apply to this model?
Use clean air filtered to 40 um at 0.15-0.7 MPa (22-100 psi) for bore 12; the maximum working pressure is 0.7 MPa and ambient range is -20 to 70 C. Adjust speed by meter-out control within 50-500 mm/s, and have us confirm allowable load and moment limits from the datasheet for your fixture.
