Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X20SAF
The AirTAC Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X20SAF is a genuine HLQ slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X20SAF
The AirTAC HLQ12X20SAF is a double-acting dual-rod slide-table cylinder that integrates an air cylinder with a linear ball-bearing guide. At 12mm bore and 20mm stroke it delivers moderate thrust for mid-range guided positioning. The double-rail ball-bearing guide provides smooth straight travel with anti-rust and dust-proof protection, and the floating joint spares the rods from side torque.
This is a genuine AirTAC part with a standard magnet for position sensing using CMSH, DMSH, or EMSH switches. The AF adjuster places an adjustable rubber stopper on the retraction side. We confirm exact thrust, dimensions, and load-moment values from the datasheet or on-page table on request.
Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X20SAF Technical Specifications
| Model | Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ12X20SAF |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQ (ball-bearing guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Choose the 12mm bore when you need moderate push force in a compact footprint; a larger bore gives more thrust but check the spec table for the verified figure. The HLQ ball-bearing guide suits clean or mildly corrosive environments where anti-rust and dust-proof performance matter, contrasting with HLS cross-roller for maximum rigidity or HLF for low-height builds. Stroke 20mm falls within the bore 12 range. The AF adjuster adds a rubber stopper on the retraction side only; the extension side uses the standard bumper. Thread is PT (R thread). We route load and moment sizing to the published tables and curves on request.
Applications
Pick-and-Place Head
Mounts a small gripper for precise part transfer between fixture positions on an assembly line.
Stopper Transfer
Diverts or deposits small components at a conveyor workstation with consistent repeatable positioning.
Assembly Stage Slide
Indexes a workpiece or tooling plate between two assembly stations with dust-proof guided travel.
FAQ
What does the AF adjuster code mean on this HLQ model?
AF indicates an adjustable rubber stopper fitted on the retraction side only; the extension side retains the standard bumper cushion.
What is the maximum operating pressure for this 12mm bore slide table?
Maximum working pressure is 0.7 MPa (100 psi). Operating range for bore 12 is 0.15-0.7 MPa (22-100 psi). Never exceed 0.7 MPa.
