Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x10-S
The AirTAC Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x10-S is a genuine HLQ slide-table cylinder, 25 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 378 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore25 mm
- Push thrust @0.5 MPa378 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port size1/8"
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x10-S
The AirTAC HLQ25X10-S is a ball-bearing slide-table cylinder that integrates a dual-rod air cylinder with a linear ball guide for straight, low-deflection table travel. Bore 25 is the largest in the HLQ range and delivers higher thrust through the dual rods, while the floating joint protects the rods from side torque. The anti-rust, dust-proof ball-bearing guide suits environments where corrosion resistance and contamination control are priorities.
This is a genuine AirTAC part with a standard sintered NdFeB magnet for position sensing; compatible sensor switches include CMSH, DMSH, and EMSH series installed in the body slots. We confirm exact thrust, dimensions, and allowable load/moment from the manufacturer datasheet or on-page spec table on request.
Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x10-S Technical Specifications
| Model | Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x10-S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQ (ball-bearing guide) |
| Bore | 25 mm |
| Push thrust @0.5 MPa | 378 N |
| Port size | 1/8" (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 25 is the largest HLQ bore and gives the highest thrust in the family; size the bore to your load rather than oversizing. The HLQ ball-bearing guide is chosen when anti-rust and dust-proof properties matter more than cross-roller rigidity (HLS). The short 10 mm stroke is within the bore 25 range and suits compact indexing or clamping motions. This model has basic bumpers at both ends with no adjustable stopper or shock absorber. Thread is PT. We route allowable load and moment sizing to the published tables and deflection curves.
Applications
Short-Stroke Indexer
Indexes a part or fixture by 10 mm with high repeatability using the ball-bearing guide for precise short-travel positioning.
Stopper Slide
Extends a stopper block 10 mm to halt a workpiece on a conveyor, then retracts to release it with dust-proof guided motion.
Clamp Actuator
Drives a clamping jaw through a short 10 mm stroke to hold a part securely during a machining or inspection step.
FAQ
Does the HLQ25X10-S include a magnet for position sensing?
Yes. The magnet is standard on every HLQ slide table; it is not an optional add-on. Compatible sensor switches are CMSH, DMSH, and EMSH series, which mount in the slots on the cylinder body.
What load and moment can this bore 25 slide table handle?
Allowable load, moment, and kinetic energy depend on the published Wmax, Emax, and moment tables plus deflection curves. We confirm the exact values for your application from the AirTAC datasheet on request.
