Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x100-S
The AirTAC Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x100-S is a genuine HLQ slide-table cylinder, 25 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 378 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore25 mm
- Push thrust @0.5 MPa378 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port size1/8"
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x100-S
The AirTAC HLQ25X100-S is a double-acting dual-rod slide-table cylinder that integrates an air cylinder with a ball-bearing linear guide. The 25 mm bore and 100 mm stroke deliver higher thrust in a compact footprint, and the dual-rod design doubles that thrust while a floating joint protects the rods from side torque. The ball-bearing guide offers anti-rust and dust-proof operation with precise, low-deflection straight-line travel.
This is a genuine AirTAC part with a standard sintered NdFeB magnet for position sensing; compatible sensor switches include CMSH, DMSH, and EMSH series mounted in the body slots. Typical materials include an aluminium-alloy body and table with carbon-steel and stainless rods, NBR seals, and a TPU bumper. We confirm exact thrust, dimensions, and load-moment values from the datasheet or on-page spec table on request.
Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x100-S Technical Specifications
| Model | Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x100-S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQ (ball-bearing guide) |
| Bore | 25 mm |
| Push thrust @0.5 MPa | 378 N |
| Port size | 1/8" (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
The 25 mm bore suits applications needing higher thrust from the HLQ ball-bearing guide family; choose a larger bore only if more push is required, as the on-page spec table lists the verified thrust for each bore. The 100 mm stroke falls within the bore 25 stroke range listed in the datasheet. Select the ball-bearing HLQ sub-family when anti-rust and dust-proof operation matter more than the ultimate rigidity of a cross-roller HLS guide.
This basic version has standard bumper cushioning without adjustable stoppers. Port threads are PT as standard; specify G for BSPP or T for NPT if needed. For load, moment, and kinetic-energy sizing, we reference the published Wmax, Emax, and moment tables and deflection curves, so contact us with your application parameters.
Applications
Pick-and-Place Head
Mounts a small gripper for precise pick-and-place of parts with the ball-bearing guide keeping deflection low over the 100 mm stroke.
Small-Parts Transfer
Transfers components between conveyor stations with dust-proof, anti-rust ball-bearing guidance suited to exposed environments.
Assembly Stage Stopper
Positions workpieces at an assembly station, using the dual-rod thrust to push parts squarely into the fixture.
FAQ
What guide type does the HLQ25X100-S use?
The HLQ series uses a ball-bearing linear guide, offering anti-rust and dust-proof operation with precise, low-deflection travel. This differs from the HLS cross-roller guide, which provides higher rigidity, and the HLF low-height cross-roller body.
What is the maximum operating pressure for this slide table?
The maximum working pressure is 0.7 MPa (100 psi). Operating pressure for the 25 mm bore is 0.15-0.7 MPa (22-100 psi). Use meter-out speed control to keep travel between 50 and 500 mm/s.
