Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x20-S
The AirTAC Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x20-S is a genuine HLQ slide-table cylinder, 25 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 378 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore25 mm
- Push thrust @0.5 MPa378 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port size1/8"
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x20-S
The AirTAC HLQ25X20-S combines a double-acting dual-rod air cylinder with a ball-bearing linear guide in a compact slide table. With bore 25 mm and a short 20 mm stroke, the guided table moves precisely with minimal deflection. The dual rod provides higher thrust for the bore size, and the floating joint prevents side-load torque on the rod. HLQ's ball-bearing guide is anti-rust and dust-proof for demanding environments.
Genuine AirTAC construction with a standard magnet fitted for CMSH, DMSH, or EMSH sensor switches. Contact us to confirm thrust values, overall dimensions, and allowable load and moment from the datasheet or on-page table.
Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x20-S Technical Specifications
| Model | Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x20-S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQ (ball-bearing guide) |
| Bore | 25 mm |
| Push thrust @0.5 MPa | 378 N |
| Port size | 1/8" (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 25 mm delivers higher thrust in the HLQ ball-bearing family; the short 20 mm stroke is ideal for compact pick-and-place or stopper actions where travel distance is minimal. Choose HLQ when anti-rust and dust-proof properties matter more than HLS cross-roller precision. Select the adjuster option (basic, or rubber stopper or shock absorber at either end) and thread (PT, G, or NPT) for your setup.
Allowable load, moment, and deflection are bore- and stroke-specific - we confirm from published tables and curves on request.
Applications
Gripper Traverse
Short 20 mm stroke positions a gripper precisely at a pick point with ball-bearing anti-rust guidance.
Stopper Mechanism
Compact 20 mm guided stop holds or releases parts on a line in dust-exposed environments.
Small-Parts Transfer
Bore 25 dual-rod slide shifts components between workstations with straight low-deflection travel.
FAQ
Does the HLQ25X20-S come with a magnet, and which sensors work with it?
Yes, a magnet is standard on every HLQ slide table - it is not an option to decline. Compatible sensor switches are CMSH, DMSH, and EMSH, which mount in the magnetic-switch slots on the body.
Can I use shock absorbers on the HLQ25X20-S bore 25?
Yes. Bore 25 supports the B-type shock-absorber adjuster option (both ends, or extension or retraction side via BS or BF codes) along with the A-type adjustable rubber stopper. Bore 6 is the only size that cannot use B-type adjusters.
