Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x30-S
1. Dual precision linear guides ensure high accuracy, high rigidity, and integrated rust/dust resistance
2. Pre-machined through-holes on slider for convenient top-side body fixation
3. Built-in locating pin holes on slider for precise alignment
4. Floating joint design prevents piston rods from bearing external torsional loads
5. Double-piston rod configuration delivers doubled output force
6. Integrated locating pin holes on main body for accurate positioning
7. Mounting screw holes on base surface and end faces for flexible installation
Category: Slide Cylinders | Brand: AirTAC | Series: HLQ
AirTAC HLQ25x30-S Dual Axis Precision Slide Cylinder Specifications
- Model: HLQ25x30-S
- Type: Dual-axis guided slide cylinder with integrated linear guide
- Bore size: 25mm
- Stroke: 30mm (±1mm adjustable)
- Operating pressure: 0.1–0.8 MPa
- Max speed: 500mm/s (with cushioning)
- Repeat positioning accuracy: ±0.01mm
- Load capacity: 30N (vertical), 60N (horizontal)
- Cushion type: Elastic buffer + external shock absorber interface
- Mounting options: Side-mount (standard), front-flange (optional)
- Material: Aluminum alloy body, chrome-plated piston rod
- Surface treatment: Black anodized slide block
- Operating temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (ISO VG32 equivalent)
- Weight: 0.82kg (excluding accessories)
- Dimensions: 130mm(L) × 50mm(W) × 60mm(H)
- Port size: M5x0.8 (dual ports for push/pull control)
- Guide rail type: Dual linear ball bearings with 4-row raceway
High-precision dual-axis pneumatic slide cylinder combining air cylinder action with precision linear guidance. Features zero-backlash ball bearing guides and hardened steel shafts (HRC60+) for repeatable micro-positioning. The integrated T-slot design allows direct mounting of tooling plates. Includes built-in magnet for position sensing compatibility.
- PCB component insertion machines
- Micro-dispensing systems for adhesives
- Optical lens alignment stations
- Semiconductor wafer handling
- Precision gauging equipment
Operational guidance:
Maintain 0.5-1mm clearance between slide block and end stoppers during installation.
Requires 5μm filtered air with 1-3 drops of ISO VG32 oil per m³. Avoid lateral moment loads exceeding 1.5Nm.
| Property | Property Value |
|---|---|
| sku | HLQ25x30-S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 30mm |
