Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x40-S
The AirTAC Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x40-S is a genuine HLQ slide-table cylinder, 25 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 378 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore25 mm
- Push thrust @0.5 MPa378 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port size1/8"
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x40-S
The AirTAC HLQ25X40-S is a double-acting dual-rod slide-table cylinder that pairs an air cylinder with a ball-bearing linear guide, so the table travels straight with minimal deflection. The dual rods double the thrust for the bore size, and the floating joint prevents side torque from loading the rods. At bore 25 mm and stroke 40 mm, this HLQ ball-bearing table delivers anti-rust, dust-proof guided motion with higher thrust suited to medium-duty positioning tasks.
This genuine AirTAC part carries a standard sintered NdFeB magnet for position sensing with CMSH, DMSH, or EMSH switches in the body slots. We confirm thrust, dimensions, and allowable load/moment from the AirTAC datasheet or on-page spec table on request so you can size with verified figures.
Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x40-S Technical Specifications
| Model | Airtac HLQ Dual-Axis Precision Slide Table Cylinder HLQ25x40-S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQ (ball-bearing guide) |
| Bore | 25 mm |
| Push thrust @0.5 MPa | 378 N |
| Port size | 1/8" (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 25 provides higher thrust than smaller bores in the HLQ family; select the bore that matches your push requirement - the on-page spec table lists the exact thrust. The HLQ ball-bearing guide is the right pick when anti-rust and dust-proof operation matter; HLS cross-roller gives higher rigidity for heavy loads, HLH offers precision straightness with three port groups, and HLF saves vertical height. This model uses the basic rubber-bumper cushion with no extra stopper; if you need adjustable end positioning, consider the A, B, AS, or AF variants. Thread is PT; G or NPT available on request. We route allowable load, moment, and deflection sizing to the published AirTAC tables and curves.
Applications
Pick-and-Place Head
Mount a small gripper on the slide table for precise part pick-up and placement where the ball-bearing guide keeps the tool centered under load.
Small-Parts Transfer
Transfer lightweight components between stations with the anti-rust, dust-proof ball-bearing guide maintaining straight travel in mildly contaminated environments.
Assembly Stage Stop
Use the slide table as a short-stroke positioning stage that presents a subassembly to the next operation with repeatable guided positioning.
FAQ
How does the HLQ ball-bearing guide differ from other AirTAC HL slide tables?
HLQ uses a ball-bearing linear guide that is anti-rust and dust-proof, suited to environments with corrosion risk or particulates. HLS uses a cross-roller guide for maximum rigidity and load capacity. HLH uses a miniature roller-ball integrated guide with the best straightness and three port groups. HLF is a low-height cross-roller body for tight vertical spaces. All are double-acting dual-rod slide tables.
What are the pressure and speed limits for the HLQ25X40-S?
Maximum working pressure is 0.7 MPa (100 psi); proof pressure is 1.2 MPa (175 psi). Operating pressure for bore 25 is 0.15-0.7 MPa (22-100 psi). Speed range is 50-500 mm/s with meter-out control. Temperature range is -20 to 70 C. We confirm allowable load, moment, and deflection from the AirTAC datasheet on request.
