Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X40SA
The AirTAC Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X40SA is a genuine HLQ slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X40SA
The AirTAC HLQL12X40SA symmetrical ball-bearing slide-table cylinder combines a double-acting dual-rod air cylinder with a dust-proof linear guide. The 12mm bore and 40mm stroke yield moderate thrust, and the ball-bearing rail ensures anti-rust precision travel with minimal deflection. Adjustable rubber stoppers at both ends give cushion control, while the floating joint keeps rods free from side torque.
This genuine AirTAC component carries a standard magnet for position sensing. CMSH, DMSH, and EMSH series sensor switches install in the magnetic-switch slots on the body. We verify thrust, overall dimensions, and load-moment ratings from the datasheet or on-page specification table whenever you need them.
Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X40SA Technical Specifications
| Model | Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X40SA |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQL (ball-bearing guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 provides moderate thrust for the HLQL series; stepping up to bore 16 or 20 increases push but adds width. The symmetrical ball-bearing guide offers anti-rust, dust-proof precision travel - a good fit where corrosion resistance matters more than the cross-roller's maximum rigidity. Stroke 40mm is within the bore's standard stroke table.
The A adjuster adds adjustable rubber stoppers at both ends for tuned end-position cushioning beyond the standard bumper. Thread is PT. For load, moment, and kinetic-energy limits we reference the published Wmax/Emax tables and deflection curves - contact us to confirm sizing for your setup.
Applications
Assembly Press Slide
Feeds a small press head into position with rubber stoppers giving repeatable end-stop cushioning on both advance and retract.
Alignment Finger Actuator
Pushes a part against a fixture wall for alignment, the 40mm stroke and symmetrical ball-bearing guide keeping the finger true.
Adjustable Stop Station
Serves as an end-position stop with tunable rubber cushions on both ends, letting operators dial in contact force for delicate workpieces.
FAQ
What does the A adjuster code mean on HLQL12X40SA?
A adds adjustable rubber stoppers at both ends of the stroke. You can tune the stopper position to fine-tune end-stop cushioning beyond the standard bumper, giving repeatable soft contact for both advance and retract.
How do I confirm the allowable load and moment for HLQL12X40SA?
We reference the published Wmax and moment tables along with deflection curves from the AirTAC datasheet. Contact us with your load, stroke, and mounting orientation and we will confirm the ratings for your application.
