Airtac JSI Series Standard Cylinder JSI100X1200
The AirTAC Airtac JSI Series Standard Cylinder JSI100X1200 is a genuine double acting JIS-standard air cylinder with a Ø100mm bore and 1200mm stroke, G1/2 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ100 mm
- Stroke1200 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM26×1.5
- CushionAdjustable, 33 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSI Series Standard Cylinder JSI100X1200
Delivering 3927 N of push force at 0.5 MPa, this double-acting JIS-standard profile cylinder saves valuable machine space by being noticeably shorter than an ISO 15552 cylinder of the same 100 mm bore. The extruded hard-anodized aluminum barrel omits external rods to resist wear, while the two-way piston seal retains grease for a long, low-friction service life. Operating at speeds of 30-800 mm/s, it features a G1/2 air port and an M26x1.5 rod-end thread.
For real-world sizing, plan for about 2356 N of actual work at 0.5 MPa, which safely lifts a 200 kg load vertically with a 2:1 margin. Because this specific SKU lacks the -S magnet, it cannot accept CMSE or DMSE position switches. The 33 mm adjustable air cushions at both ends absorb end-of-stroke impact, and related types like the JSID double-rod or JSIJ adjustable-stroke variants cover specialized motion needs.
Airtac JSI Series Standard Cylinder JSI100X1200 Technical Specifications
| Model | Airtac JSI Series Standard Cylinder JSI100X1200 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 1200 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M26×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 33 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac JSI Series Standard Cylinder JSI100X1200
| JSI | JIS-standard profile cylinder (double-acting type). |
|---|---|
| 100 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSI Series Standard Cylinder JSI100X1200 Is Used
Pallet Transfer Line
Pushes heavy loaded pallets between machining centers over a 1200 mm gap using its 3927 N push force at 0.5 MPa.
Automated Storage Crane
Drives the horizontal extractor arm in high-bay racking, where the compact JIS profile saves overhead clearance.
Injection Mold Ejector
Actuates a large secondary ejection mechanism for automotive trim parts, relying on the 33 mm cushions to halt smoothly.
Is the Airtac JSI Series Standard Cylinder JSI100X1200 the Right Cylinder?
When sizing this 100 mm bore unit, the neighboring JSI80 offers 2513 N push at 0.5 MPa for lighter loads, while the larger JSI125 steps up to 6136 N if your application demands more power. Since this 1200 mm stroke is highly extended, you must use an external guide to prevent rod bending and manage side loads. Note that a standard cylinder drifts when air is lost or the valve is centered; the cushion only decelerates the piston near stroke end and acts as no lock. For secure load holding, install an external rod lock or a pilot-operated check valve.
