Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-10S
The AirTAC Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-10S is a genuine double acting, adjustable stroke JIS-standard air cylinder with a Ø100mm bore and 100mm stroke, G1/2 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ100 mm
- Stroke100 mm
- Port sizeG1/2
- Acting typeDouble acting, adjustable stroke
- Rod threadM26×1.5
- CushionAdjustable, 33 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-10S
Delivering 3927 N of push force at 0.5 MPa, this 100 mm bore JIS profile cylinder integrates an external adjuster that shortens the extend stroke by up to 10 mm on site. The nominal 100 mm stroke remains the maximum travel, letting you fine-tune the end position without swapping the actuator. A built-in piston magnet ships standard, ready for CMSE or DMSE sensors in the side grooves.
Built with a hard-anodized aluminum barrel and no exposed tie rods, the body is noticeably shorter and more compact than a same-bore ISO 15552 cylinder. It handles about 2356 N of real work safely, translating to roughly 200 kg lifted vertically with a 2:1 margin. The G1/2 port feeds the 32 mm rod, and while the 33 mm adjustable air cushions decelerate smoothly, remember a plain cylinder drifts without live air, so fit an external rod lock for held loads.
Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-10S Technical Specifications
| Model | Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-10S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/2 |
| Rod thread | M26×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 33 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-10S
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 100 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-10S Is Used
Press Fit Tuning
Dial in the exact 90-100 mm extend position on-site to seat bearings without bottoming out the tooling.
Divert Arm Stroke
Adjust the extend stop by 10 mm to fine-tune the pusher distance for varying package widths on the line.
Pallet Stop Gate
Set a precise 95 mm end position to act as a fixed physical stop for incoming pallets on a transfer deck.
Is the Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-10S the Right Cylinder?
When sizing, the 80 mm bore offers 2513 N push at 0.5 MPa for lighter frames, while the 125 mm bore jumps to 6136 N if you need extra thrust. This 100 mm actuator provides 5497 N at 0.7 MPa, making it ideal for mid-heavy pressing. The -10 mm adjustable window is perfect for sharing one spare across multiple stroke variants or dialing in final positioning on-site. You can mount it via FA, LB, TC, TCM1, or TCM2 brackets. The -S magnet enables precise end-of-stroke detection. Because the stroke is 100 mm, always guide the load to prevent side-load wear on the rod seals.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-10S FAQ
At 0.5 MPa it pushes 3927 N and pulls 3574 N. At 0.7 MPa it pushes 5497 N and pulls 5003 N. The theoretical maximum is 801 kgf at 1.0 MPa. This 100 mm bore unit uses a G1/2 port, a 32 mm rod, and 33 mm adjustable air cushions at both ends.
The external stop screw lets you shorten the extend stroke by up to 10 mm on site. The usable extend range is 90-100 mm, with the nominal 100 mm acting as the maximum travel. The retract end remains fixed. This stop only sets the end position and does not lock the load.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
