Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40
The AirTAC Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40 is a genuine double acting, adjustable stroke JIS-standard air cylinder with a Ø100mm bore and 1000mm stroke, G1/2 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ100 mm
- Stroke1000 mm
- Port sizeG1/2
- Acting typeDouble acting, adjustable stroke
- Rod threadM26×1.5
- CushionAdjustable, 33 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40
Delivering 3927 N of push force at 0.5 MPa, this 100 mm bore JIS profile cylinder brings compact power to long-stroke automation. Its hard-anodized extruded aluminium barrel leaves out external retaining rods, making the overall body shorter and more compact than a same-bore ISO 15552 unit. The G1/2 port feeds the 32 mm piston rod to deliver substantial thrust.
The external stop screw lets you trim the extend stroke by up to 40 mm on site, giving a usable forward travel of 960-1000 mm without swapping the actuator. This on-site end-position tuning is ideal for dialling in shared spares across stroke variants. Handling about 2356 N of real work, it lifts roughly 200 kg vertically with a 2:1 safety margin. Note this SKU lacks a magnet and cannot take CMSE/DMSE sensors.
Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40 Technical Specifications
| Model | Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/2 |
| Rod thread | M26×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 33 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 100 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40 Is Used
Long-Transfer Pushing
Moves heavy pallets along a 1000 mm conveyor section, using the 40 mm adjuster to dial the exact push-off distance without repositioning the cylinder.
Heavy Plunge Pressing
Provides 3927 N of downward thrust for seating large components, with the external stop screw allowing precise depth trimming on the production line.
Warehousing Diversion
Acts as a long-reach diverter arm in sorting hubs, trimming the extend stroke by up to 40 mm to accommodate varying package sizes on the fly.
Is the Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40 the Right Cylinder?
When sizing, the 80 mm bore offers 2513 N push at 0.5 MPa, while the 125 mm jumps to 6136 N; this 100 mm actuator sits comfortably in the middle at 3927 N. The -40 mm adjuster is invaluable when you need to fine-tune a long forward end position on the factory floor rather than machining a custom stop. Mounting options include FA, LB, TC, TCM1 and TCM2. Because this is a 1000 mm stroke, always use external guides to prevent rod bending and side-load damage. Select the -S variant if your application requires CMSE/DMSE position sensing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40 FAQ
At 0.5 MPa it provides 3927 N push and 3574 N pull. At 0.7 MPa it delivers 5497 N push and 5003 N pull. The theoretical maximum force is 801 kgf at 1.0 MPa.
The nominal 1000 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke on site by up to 40 mm, yielding a usable forward travel of 960-1000 mm. The retract end remains fixed. This mechanism only sets the end position; it is not a load lock, so use an external rod lock or pilot-operated check valve if you need to hold a load on air loss.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
