Airtac MD Multi-Position Clamping Cylinder MD20X60
The AirTAC Airtac MD Multi-Position Clamping Cylinder MD20X60 is a genuine MD multi-mount cylinder (double acting), 20 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 157.1 N of push force at 0.5 MPa. A bumper cushions the impact.
- TypeMulti-mount, double acting
- SeriesMD (standard)
- Bore20 mm
- Push thrust @0.5 MPa157.1 N
- Operating pressure0.15 - 1.0 MPa (22 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWithout magnet
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MD Multi-Position Clamping Cylinder MD20X60
The MD20X60 is an AirTAC MD multi-mount cylinder: a compact square-body, double-acting pneumatic cylinder that fixes from 6 directions (front, back, left, right, top and bottom) and mounts side by side to save space. With the maximum 60 mm stroke for the 20 mm bore, it reaches further into fixtures and stations while still delivering a theoretical push thrust of 157.1 N at 0.5 MPa, cushioned by a bumper at each end.
This is a genuine AirTAC part. The MD family is the standard multi-mount design; choose the MK family where the rod must not rotate. This SKU carries no trailing S, so the cylinder is supplied without a magnet. We confirm dimensions and sizing from the datasheet on request.
Airtac MD Multi-Position Clamping Cylinder MD20X60 Technical Specifications
| Model | Airtac MD Multi-Position Clamping Cylinder MD20X60 |
|---|---|
| Type | Multi-mount cylinder, double acting |
| Series | MD (standard) |
| Bore | 20 mm |
| Push thrust @0.5 MPa | 157.1 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | Without magnet |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 1.0 MPa (22 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Size the bore by thrust: at 0.5 MPa a 20 mm bore double-acting cylinder produces 157.1 N push and 131.9 N pull. MD lets the rod rotate; MK prevents rotation. Acting choices are double (MD), single push (MSD), single pull (MTD), double rod (MDD) or adjustable stroke (MDJ). This 60 mm stroke is at the top of the bore 20 table - the short covers caution against specifying an over-long stroke, so verify the travel you truly need. No trailing S means no magnet; PT thread is standard with G optional. Route side-load questions to us.
Applications
Push-off transfer
Use the full 60 mm stroke to push parts off a conveyor or out of a nest at a transfer point, keeping the body footprint small in a crowded frame.
Lift-and-lower nest
Mount the cylinder from the top or bottom of a small lifting nest, using 157.1 N of push at 0.5 MPa to raise light workpieces between stations.
Slide and position fixture
Fix from any of 6 directions to drive a compact slide or positioner in a fixture, with the 60 mm reach covering longer indexing moves than short-stroke bodies allow.
FAQ
Does MD20X60 include a magnet?
No. This SKU has no trailing S, so it is supplied without a magnet. If you need position sensing via magnetic switches, order the MD20X60S version instead - the S at the end of the code is what adds the magnet.
Is 60 mm the maximum stroke for this bore, and can the rod turn?
For a 20 mm bore double-acting MD cylinder the stroke table runs up to 60 mm, so this model is at the top of the range - the short covers caution against over-long strokes, and adjustable-stroke MDJ variants add a 10/20/30 mm range if needed. The MD rod is free to rotate; specify the MK no-rotating family to prevent rotation. Side-load limits come from the datasheet.
