Airtac MDJ Adjustable Cylinder MDJ10X15-10S
The AirTAC Airtac MDJ Adjustable Cylinder MDJ10X15-10S is a genuine MD multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact.
- TypeMulti-mount, adjustable stroke
- SeriesMD (standard)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.15 - 1.0 MPa (22 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MDJ Adjustable Cylinder MDJ10X15-10S
A multi-mount cylinder is a compact square-body air cylinder that fixes from six directions - front, back, left, right, top and bottom - and mounts side by side to save space. This MDJ10X15-10S is the adjustable-stroke member of the MD family: double acting, 10 mm bore, 15 mm basic stroke plus a 10 mm adjustment range you can trim in service. At 0.5 MPa it gives a theoretical push force of 39.3 N (slightly less on the pull side), cushioning is a bumper, magnetic-switch slots are machined around the body, and it runs at 30-500 mm/s on air filtered to 40 um.
This is a genuine AirTAC part. The MD family is the standard multi-mount design in which the rod is free to rotate; only the MK family adds a no-rotating plate. The trailing S means this model carries a magnet for position sensing. Overall dimensions for your stroke and sizing checks can be confirmed from the AirTAC datasheet on request.
Airtac MDJ Adjustable Cylinder MDJ10X15-10S Technical Specifications
| Model | Airtac MDJ Adjustable Cylinder MDJ10X15-10S |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MD (standard) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 1.0 MPa (22 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Pick MD (rotation allowed) over MK (no-rotating plate) when the rod may turn. This MDJ is double acting with an adjustable stroke: 15 mm basic plus a 10 mm adjustment range, well inside the 35 mm stroke table for a 10 mm bore, and the short covers guard against over-long strokes. The trailing S orders it with a magnet; the thread is PT as standard with G optional. Operating range is 0.15-1.0 MPa (22-145 psi); confirm side-load limits from the datasheet or ask us.
Applications
Small-parts clamping
Bolted from the side or bottom of a tight fixture, the 10 mm square body clamps small components with 39.3 N push at 0.5 MPa while the bumper cushions every clamp cycle.
Jig positioning
Mounted side by side on an assembly jig, the adjustable stroke lets you trim the 15 mm travel to locate parts precisely without shimming or re-drilling mount holes.
Indexing stopper
Fixed from the top of a conveyor line, the double-acting rod rises to stop indexed parts at a station, and the magnet signals the stopper position back to the PLC.
FAQ
What does the -10 in MDJ10X15-10S mean?
It is the adjustable stroke range. MDJ marks an adjustable-stroke, double-acting multi-mount cylinder: 10 mm bore, 15 mm basic stroke plus a 10 mm adjustment range you can set in service. The trailing S orders the magnet; without an S the cylinder ships without one.
How can this cylinder be mounted?
The square body fixes from six directions - front, back, left, right, top and bottom - and units mount side by side to save space. Dimensions for your stroke and any side-load figures come from the AirTAC datasheet; contact us and we will confirm them.
