Airtac MDJ Adjustable Cylinder MDJ10X15-20S
The AirTAC Airtac MDJ Adjustable Cylinder MDJ10X15-20S is a genuine MD multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact.
- TypeMulti-mount, adjustable stroke
- SeriesMD (standard)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.15 - 1.0 MPa (22 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MDJ Adjustable Cylinder MDJ10X15-20S
A multi-mount cylinder is a compact square-body air cylinder that fixes from six directions - front, back, left, right, top and bottom - and mounts side by side to save space. This MDJ10X15-20S is the adjustable-stroke member of the MD family: double acting, 10 mm bore, 15 mm basic stroke plus a wide 20 mm adjustment range for setups that change. At 0.5 MPa it gives a theoretical push force of 39.3 N (slightly less on the pull side), cushioning is a bumper, magnetic-switch slots are machined around the body, and it runs at 30-500 mm/s on air filtered to 40 um.
This is a genuine AirTAC part. The MD family is the standard multi-mount design in which the rod is free to rotate; only the MK family adds a no-rotating plate. The trailing S means this model carries a magnet for position sensing. Overall dimensions for your stroke and sizing checks can be confirmed from the AirTAC datasheet on request.
Airtac MDJ Adjustable Cylinder MDJ10X15-20S Technical Specifications
| Model | Airtac MDJ Adjustable Cylinder MDJ10X15-20S |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MD (standard) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 1.0 MPa (22 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Pick MD (rotation allowed) over MK (no-rotating plate) when the rod may turn. This MDJ is double acting with an adjustable stroke: 15 mm basic plus a 20 mm adjustment range, comfortably within the 35 mm stroke table for a 10 mm bore, and the short covers guard against over-long strokes. The trailing S orders it with a magnet; the thread is PT as standard with G optional. Operating range is 0.15-1.0 MPa (22-145 psi); confirm side-load limits from the datasheet or ask us.
Applications
Part ejection
Cylinder bodies bolted in a row beneath a chute eject small parts in sequence; the 20 mm adjustment range lets you tune the 15 mm push travel as the tooling changes.
Fixture positioning
Fixed from the front of a machining fixture, the double-acting rod advances to a trimmed position within its 15 mm plus 20 mm range to seat parts before processing.
Gate actuation
Side-mounted next to a diverting gate on a conveyor, the cylinder strokes the gate across the lane, with the bumper absorbing the motion at each end of travel.
FAQ
Why choose the MDJ10X15-20S over a fixed-stroke cylinder?
The -20 suffix adds a 20 mm adjustment range on top of the 15 mm basic stroke, so one cylinder can be re-tuned in service as the stroke requirement changes. It is still double acting with a 10 mm bore, 39.3 N theoretical push at 0.5 MPa, and the trailing S means it includes the magnet.
What stroke limits apply?
For a 10 mm double-acting multi-mount cylinder the stroke table tops out at 35 mm; keeping the stroke short preserves the compact covers, so avoid over-long strokes. This model carries 15 mm basic plus 20 mm adjustment, and exact body dimensions come from the AirTAC datasheet - we can confirm them for you.
