Airtac MDJ Adjustable Cylinder MDJ10X35-10S
The AirTAC Airtac MDJ Adjustable Cylinder MDJ10X35-10S is a genuine MD multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact.
- TypeMulti-mount, adjustable stroke
- SeriesMD (standard)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.15 - 1.0 MPa (22 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MDJ Adjustable Cylinder MDJ10X35-10S
The MDJ10X35-10S is an AirTAC MDJ adjustable-stroke multi-mount cylinder with a 10 mm bore, 35 mm stroke and an extra 10 mm adjustable range, letting you trim the effective stroke after fitting. The square body fixes from 6 directions (front, back, left, right, top and bottom) and units mount side by side, saving space in compact fixtures. As a double acting bore 10 unit it delivers 39.3 N of theoretical push thrust at 0.5 MPa, with a bumper for cushioning.
This is a genuine AirTAC part. The MD family is the standard multi-mount design; the MK family instead adds a no-rotating plate to stop rod rotation. This SKU carries the S suffix, so a magnet is fitted for magnetic switch detection. We confirm dimensions and sizing from the datasheet on request.
Airtac MDJ Adjustable Cylinder MDJ10X35-10S Technical Specifications
| Model | Airtac MDJ Adjustable Cylinder MDJ10X35-10S |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MD (standard) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 1.0 MPa (22 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Bore 10 gives 39.3 N push at 0.5 MPa (33.0 N pull); step up a bore if you need more force. Pick MD where rod rotation is acceptable and MK where it must be prevented, and MDJ when the stroke must be adjustable on the machine. Double acting MDJ gives powered extend and retract. Bore 10 double acting strokes run up to 35 mm, and the MDJ adds a 10/20/30 mm adjustable range on top. The S suffix here means the magnet is fitted; drop it if you do not need switch detection. Thread is PT by default or G. Avoid over-long strokes on the short covers, and route side-load questions to us.
Applications
Indexed part stop
Stop parts at a repeatable point on a small conveyor, using the magnet for end-of-stroke switch feedback and the adjustable range to fine-tune the stop position.
Fixture clamp with position check
Clamp light workpieces in an assembly jig and confirm extend and retract via magnetic switches on the compact body, fixed from any of 6 directions.
Compact eject or push-off
Push small parts off a fixture or chute in a tight cell, banking units side by side where a tie-rod cylinder would not fit.
FAQ
What does the S in MDJ10X35-10S mean?
The trailing S means this cylinder is built with a magnet, so reed or hall-effect switches can detect piston position in the slots around the body. The same code without the S is the identical cylinder without a magnet, and PT thread is the default with G available.
What is the adjustable stroke for, and what are the limits?
The -10 in the code adds a 10 mm adjustable range on top of the 35 mm base stroke, so you can set the exact working stroke on the machine. Keep within the bore 10 double acting stroke table, avoid over-long strokes that load the short covers, and confirm dimensions and side-load limits from the datasheet.
