Airtac MDJ Adjustable Cylinder MDJ10X5-10S
The AirTAC Airtac MDJ Adjustable Cylinder MDJ10X5-10S is a genuine MD multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact.
- TypeMulti-mount, adjustable stroke
- SeriesMD (standard)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.15 - 1.0 MPa (22 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MDJ Adjustable Cylinder MDJ10X5-10S
The MDJ10X5-10S is an AirTAC MD-series adjustable-stroke multi-mount cylinder with a 10 mm bore, a short 5 mm base stroke and an extra 10 mm adjustable range, supplied with magnet. The multi-mount square body fixes from 6 directions (front, back, left, right, top and bottom) and mounts side by side to save space, with magnetic-switch slots around the body and high guide precision without added lubricant. Double acting with a TPU bumper cushion, it runs at 30-500 mm/s and provides a theoretical push thrust of 39.3 N at 0.5 MPa on this bore.
This is a genuine AirTAC part. The MD family is the standard multi-mount design; the MK family is the no-rotating version that stops the rod turning with a plate and fixed rod - this model allows rotation. The trailing S in the SKU confirms this unit is built with a magnet, using the body's switch slots for position detection. Medium is air filtered to 40 um, proof pressure 1.5 MPa (215 psi), temperature -20 to 70 C (0 to 150 C only with the optional high-temperature seal material). We confirm exact dimensions and sizing from the datasheet on request.
Airtac MDJ Adjustable Cylinder MDJ10X5-10S Technical Specifications
| Model | Airtac MDJ Adjustable Cylinder MDJ10X5-10S |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MD (standard) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 1.0 MPa (22 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Pick the 10 mm bore for light-duty jobs within its theoretical 39.3 N push thrust at 0.5 MPa (33.0 N pull side); move to bore 16-32 when you need more force. MDJ gives double acting action plus adjustment: the rod stops anywhere in the extra 10 mm range beyond the 5 mm base stroke, so you can set a precise final position after installation. The S suffix means magnet is included; the same cylinder without S has no magnet.
Thread is PT as standard with G available as an option on the M5x0.8 ports used on bore 6-25. Standard MD permits rod rotation - choose MK where rotation must be prevented. Keep stroke within the bore's table, since the short cover cautions against over-long strokes on this compact multi-mount body. Confirm side-load limits and per-stroke dimensions from the datasheet, or ask us.
Applications
Indexed gate with position signal
A short-stroke gate or interlock on an automation cell; the included magnet and body switch slots signal open and closed positions back to the PLC, and the adjustable range dials in the exact stop point.
Pick-and-place lift confirm
Lifts small parts a few millimetres between stations and confirms completion via the magnet; the 6-direction fixing lets the cylinder mount from above, below or the side of a cramped head plate.
Small-parts clamp with detection
Clamps tiny components during gluing or testing, with the magnet verifying the clamp is made; units mount side by side for multi-point clamping in minimal space.
FAQ
What is the difference between MDJ10X5-10 and MDJ10X5-10S?
Only the magnet. The trailing S on the MDJ10X5-10S means the cylinder is built with a magnet for position-detecting switches in the slots around the body. The MDJ10X5-10 without the S is supplied without a magnet. Both are double acting, bore 10, 5 mm stroke with a 10 mm adjustable range.
Where can this multi-mount cylinder be fixed from?
The square body can be fixed from 6 directions: front, back, left, right, top and bottom, and cylinders can be mounted side by side to save space. Allowable side load and overall dimensions are not quoted here - confirm them from the datasheet or ask us.
