Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA
The AirTAC Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA is a genuine double acting JIS-standard round-body mini air cylinder with a Ø20mm bore and 10mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel for mildly corrosive environments. For the same bore and stroke it is shorter than an ISO 6432 cylinder, saving mounting space.
- BoreØ20 mm
- Stroke10 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM8×1.25
- CushionFixed TPU bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA
Generating 157 N of push force at 0.5 MPa, the AirTAC MF20X10CA is a compact 20 mm bore double-acting mini cylinder built to JIS standards. Because its riveted SUS304 stainless round body is shorter than an equivalent ISO 6432 unit, it saves valuable mounting length in tight machinery. The 1/8" port and 10 mm stroke make it ideal for very short linear movements.
The piston relies on a two-way oil-retaining seal for smooth friction life, while fixed TPU bumper pads and a front-cover anti-impact pad absorb end-of-stroke shock. Plan for roughly 94 N of actual work at 0.5 MPa, which means it can safely lift about 8 kg vertically with a 2:1 safety margin. This specific SKU lacks a magnet, so it cannot host CMSG, DMSG, or EMSG reed switches.
Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA Technical Specifications
| Model | Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA |
|---|---|
| Series | MF JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed TPU bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MF/MFC (JIS-standard) datasheet. Barrel: SUS304 stainless steel; covers: aluminum alloy (round-body, riveted rolling-packed construction). Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 157 N | 132 N |
| 0.7 MPa | 220 N | 185 N |
| Max (@1.0 MPa) | 32 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA
| MF | JIS-standard round-body mini cylinder (double-acting). |
|---|---|
| 20 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MF-family variants: MF / MFC (double acting ±cushion), MSF / MTF (single acting push / pull), MFD / MFCD (double rod ±cushion), MFJ / MFCJ (adjustable stroke ±cushion). Back covers CA / U / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA Is Used
Clamp Actuation
Provides a rapid 10 mm stroke to secure small electronic components on a PCB assembly fixture, utilising its 94 N safe working load effectively.
Part Ejection
Pushes lightweight moulded plastic parts out of a machining centre using the 157 N push force available at 0.5 MPa.
Diverter Gate
Pivots via the CA rear cover to flick small packages on a packaging line where the JIS short-body footprint prevents frame interference.
Is the Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA the Right Cylinder?
When sizing this actuator, stepping up to the MF25 bore increases the 0.5 MPa push force to 245.3 N for heavier duties, while no smaller standard MF bore exists below 20 mm. The included CA back cover provides a rear pivot mount, perfect for angular load articulation. Because the 10 mm stroke is extremely short, side-load risks are minimal, but remember that air pressure alone will not hold a load if supply drops—the bumper pads only decelerate the stroke end, so add a pilot check valve for position holding.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA FAQ
This 20 mm bore cylinder features a 1/8" port and an M8x1.25 male rod thread. At 0.5 MPa it generates 157 N push and 131.9 N pull. At 0.7 MPa the push is 219.8 N and pull is 184.7 N. The theoretical maximum force is 32 kgf at 1.0 MPa.
No, this specific SKU does not include the -S magnet option, so it cannot support CMSG, DMSG, or EMSG switches. You would need the -S variant for position sensing. It uses fixed TPU bumper pads rather than an adjustable air cushion to decelerate the stroke end.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
Request a Quote for Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10CA
Send us the quantity and destination. We confirm price, stock and lead time — usually within 7-8 hours.
