Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SUTC
The AirTAC Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SUTC is a genuine double acting JIS-standard round-body mini air cylinder with a Ø40mm bore and 40mm stroke, 1/4" air ports and a SUS304 stainless-steel barrel for mildly corrosive environments. For the same bore and stroke it is shorter than an ISO 6432 cylinder, saving mounting space.
- BoreØ40 mm
- Stroke40 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM14×1.5
- CushionFixed TPU bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SUTC
Delivering 628.3 N of push force at 0.5 MPa, this 40 mm bore double-acting mini cylinder is built around a SUS304 stainless barrel with riveted aluminium covers that resist mild corrosion and washdown. Because the JIS-standard round body is physically shorter than a comparable ISO 6432 unit for the same 40 mm stroke, it saves valuable mounting length in tight machinery. The piston relies on a two-way oil-retaining seal for long life, while fixed TPU bumper pads and a front-cover anti-impact pad absorb stroke-end shock.
For practical sizing, plan for about 377 N of real work at 0.5 MPa, which safely lifts roughly 32 kg vertically with a 2:1 margin. This SKU includes a built-in magnet for position sensing and uses a 1/4 inch port. If you need adjustable end-cushioning for high-speed cycles, consider the MFC variant instead of this base model.
Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SUTC Technical Specifications
| Model | Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SUTC |
|---|---|
| Series | MF JIS mini cylinder |
| Bore size | Ø40 mm |
| Stroke | 40 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M14×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed TPU bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MF/MFC (JIS-standard) datasheet. Barrel: SUS304 stainless steel; covers: aluminum alloy (round-body, riveted rolling-packed construction). Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø40mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | 739 N |
| Max (@1.0 MPa) | 128 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SUTC
| MF | JIS-standard round-body mini cylinder (double-acting). |
|---|---|
| 40 | Bore size in mm. |
| ×40 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MF-family variants: MF / MFC (double acting ±cushion), MSF / MTF (single acting push / pull), MFD / MFCD (double rod ±cushion), MFJ / MFCJ (adjustable stroke ±cushion). Back covers CA / U / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SUTC Is Used
Package Diverting
Uses the 527.8 N pull force at 0.5 MPa to actuate a routing gate on a high-speed packaging conveyor, fitting neatly into the tight transfer gap.
Press Fit Station
Pushes small bearings into housings on an assembly line, relying on the 628.3 N extension force while the TC trunnion absorbs side-moment loads.
Pallet Stop Gate
Controls pallet flow in a washdown-prone dispatch zone, where the SUS304 stainless barrel prevents mild corrosion from ambient moisture.
Is the Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SUTC the Right Cylinder?
When sizing this 40 mm bore, step down to the MF32 if your application only requires 402.2 N of push force at 0.5 MPa, as there is no larger standard MF bore available for higher loads. This specific configuration includes a U flat-end rear cover and a TC trunnion mount, which accommodates pivoting frameworks. The integrated -S magnet directly supports CMSG, DMSG, and EMSG electronic or reed switches.
Remember that fixed TPU bumpers only decelerate the stroke end; they do not act as a brake. If air pressure drops or the valve centers, the piston will drift and drop the load. To secure a vertical load safely, install an external rod lock or a pilot-operated check valve alongside this cylinder.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SUTC FAQ
The 40 mm bore uses a 1/4 inch port and an M14x1.5 male rod thread. At 0.5 MPa it pushes 628.3 N and pulls 527.8 N. At 0.7 MPa it pushes 879.6 N and pulls 738.9 N. The theoretical maximum force is 128.1 kgf at 1.0 MPa.
The JIS-standard round body is shorter than an ISO 6432 cylinder for the same 40 mm stroke, saving mounting length. The included -S magnet allows direct mounting of CMSG, DMSG, or EMSG switches for position detection.
