Airtac MKJ Adjustable Cylinder MKJ10X20-20S
The AirTAC Airtac MKJ Adjustable Cylinder MKJ10X20-20S is a genuine MK multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact. As an MK unit a fixed rod stops the piston rod rotating.
- TypeMulti-mount, adjustable stroke
- SeriesMK (no-rotating)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MKJ Adjustable Cylinder MKJ10X20-20S
The MKJ10X20-20S is a compact AirTAC multi-mount cylinder with a square body that fixes from 6 directions - front, back, left, right, top and bottom - and mounts side by side to save space. As an MK no-rotating type, its fixed rod and plate stop the piston rod from turning, so the rod face stays oriented. The 10 mm bore and 20 mm stroke, extendable by a 20 mm adjustable range, produce about 39.3 N of theoretical push thrust at 0.5 MPa (33.0 N on the pull side), with a bumper for cushioning.
This is a genuine AirTAC part in the no-rotating MK family, the counterpart to the standard MD series. The trailing S in the code means this SKU includes a magnet for switch sensing in the slots around the body. It runs on air filtered to 40 um at 0.2-1.0 MPa (28-145 psi), with 1.5 MPa (215 psi) proof pressure and -20 to 70 C operation (0 to 150 C only with the optional high-temperature seal material). We confirm dimensions and sizing from the datasheet on request.
Airtac MKJ Adjustable Cylinder MKJ10X20-20S Technical Specifications
| Model | Airtac MKJ Adjustable Cylinder MKJ10X20-20S |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MK (no-rotating) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Pick the 10 mm bore for jobs needing about 39.3 N of push at 0.5 MPa; bores 16-32 raise the thrust in the same square footprint. MK (this series) prevents rod rotation; MD allows it - match the series to whether your part must stay square. Acting types: double acting (this model), single push (MSK), single pull (MTK), double rod (MKD), adjustable stroke (MKJ). This SKU's 20 mm stroke carries a 20 mm adjustable range on top; keep the total within the short-stroke limits the compact covers impose. The trailing S adds the magnet; choose PT thread by default or G - confirm side-load limits and exact dimensions from the datasheet or ask us.
Applications
Stopper on a transfer line
Stop flowing parts at a station with a non-rotating stopper blade, and use the magnet signal to confirm the blade is fully retracted before parts resume.
Test station clamping
Hold small assemblies under a test probe in a bench-top fixture; the adjustable stroke sets clamping reach and the no-rotating rod keeps contact pads square.
Compact pick-and-place
Lower a suction or gripper head onto small parts where space is tight; the 6-way body mounting and side-by-side layout fit multi-axis compact gantries.
FAQ
How does MKJ10X20-20S differ from a standard MD cylinder of the same size?
Both are multi-mount cylinders, but MK is the no-rotating type: a fixed rod and plate stop the piston rod turning, so the rod face keeps its orientation - useful where a blade or pad must stay square. MD allows rotation. This SKU also has the S magnet and a 20 mm adjustable range on its 20 mm stroke.
What should I watch out for when applying this cylinder?
Keep the set stroke within the short-stroke capability of the compact covers - the design cautions against over-long strokes at this bore. Also confirm the exact overall dimensions for your set stroke from the datasheet, and check any side-load on the rod with us before finalising the fixture.
