Airtac MKJ Adjustable Cylinder MKJ10X25-10S
The AirTAC Airtac MKJ Adjustable Cylinder MKJ10X25-10S is a genuine MK multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact. As an MK unit a fixed rod stops the piston rod rotating.
- TypeMulti-mount, adjustable stroke
- SeriesMK (no-rotating)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MKJ Adjustable Cylinder MKJ10X25-10S
The MKJ10X25-10S is an AirTAC multi-mount cylinder: a compact square-body unit that fixes from 6 directions (front, back, left, right, top and bottom) and mounts side by side with identical units to save space. With a 10 mm bore, double acting operation and a 25 mm stroke adjustable over an additional 10 mm, it suits short, precise movements in tight fixtures. At 0.5 MPa it delivers a theoretical push force of about 39.3 N, and cushioning is provided by a bumper.
This is a genuine AirTAC part. MK is the no-rotating family: a fixed rod and plate stop the piston rod from turning, unlike the standard MD family where the rod can rotate. As the SKU shows, this model includes a magnet for position detection. We confirm overall dimensions and sizing help from the datasheet on request.
Airtac MKJ Adjustable Cylinder MKJ10X25-10S Technical Specifications
| Model | Airtac MKJ Adjustable Cylinder MKJ10X25-10S |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MK (no-rotating) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Choose the 10 mm bore when the job needs about 39.3 N push at 0.5 MPa; smaller bores give less force, larger bores more. MK gives you a non-rotating rod; pick the standard MD family if rod rotation is acceptable. This is a double acting, adjustable-stroke unit: the 25 mm stroke sits within the bore 10 table (up to 35 mm for double acting), and the -10 suffix adds a 10 mm adjustable range on top. Keep the stroke short - an over-long stroke on a compact body is best avoided. The S suffix means this SKU includes a magnet; drop it if you do not need position detection. Thread is PT as standard; G is available. Side-load limits and exact dimensions: confirm from the datasheet or ask us.
Applications
Jig positioning between stations
The magnet allows end-of-stroke detection, so the non-rotating rod can advance a part to a known position in a jig before the next operation starts.
Small-parts clamping
Side-by-side fixing lets several 10 mm bore cylinders clamp multiple points of a small workpiece from one compact fixture, each with a set stroke stop.
Gate and stopper actuation
Mounted top or bottom on a conveyor line, the cylinder raises and lowers a stopper or gate in a tight footprint, with the bumper cushioning each stop.
FAQ
What does the S at the end of MKJ10X25-10S mean?
The trailing S means this cylinder is supplied with a magnet, which allows position detection near the body. The magnet is optional on the MK family: the same model without the S (MKJ10X25-10) has no magnet. Sensor selection should be confirmed from the catalogue.
How does the no-rotating feature help my application?
A plate, brass bushing and fixed rod stop the piston rod from turning during extension and retraction. That keeps workpieces, gates or levers facing the same direction without an external anti-rotation guide. Allowable side-load figures and exact dimensions are given in the datasheet, which we can supply on request.
