Airtac MKJ Adjustable Cylinder MKJ10X30-20S
The AirTAC Airtac MKJ Adjustable Cylinder MKJ10X30-20S is a genuine MK multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact. As an MK unit a fixed rod stops the piston rod rotating.
- TypeMulti-mount, adjustable stroke
- SeriesMK (no-rotating)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MKJ Adjustable Cylinder MKJ10X30-20S
The MKJ10X30-20S is an AirTAC MK-family multi-mount cylinder: a compact square-body actuator you can fix from 6 directions (front, back, left, right, top and bottom) and mount side by side with neighbours to save panel space. Magnetic-switch slots are machined around the body, guide precision is high, and no added lubricant is needed. This unit is double acting, no-rotating, with a 10 mm bore and a 30 mm stroke that carries an extra 20 mm of adjustable stroke, so the effective stroke can be fine-trimmed in place. At 0.5 MPa the bore-10 push side gives about 39.3 N of theoretical thrust, and cushioning is a bumper.
This is a genuine AirTAC part. The MK family prevents rod rotation with a fixed rod, no-rotating plate and brass bushing, while the MD family is the standard version that allows rotation - choose MK when the load must not turn. Magnet is fitted on this SKU, as shown by the trailing S. Operating pressure is 0.2-1.0 MPa (28-145 psi) for this bore, the medium is air filtered to 40 um, and temperature range is -20 to 70 C (0-150 C only with the optional high-temperature seal material). We confirm dimensions and sizing from the datasheet on request.
Airtac MKJ Adjustable Cylinder MKJ10X30-20S Technical Specifications
| Model | Airtac MKJ Adjustable Cylinder MKJ10X30-20S |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MK (no-rotating) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Bore sets thrust: this 10 mm bore delivers about 39.3 N push at 0.5 MPa (double acting), so pick a larger bore if your work needs more force. MK is the no-rotating family - rod rotation is prevented - while MD is the standard family where rotation is allowed. Acting type: this is a double-acting MKJ adjustable-stroke unit; single-acting push (MSK) and pull (MTK), double-rod (MKD) and standard (MK) variants also exist. The 30 mm stroke sits inside the bore-10 double-acting table (up to 35 mm), and the J variant adds 10, 20 or 30 mm of adjustable range on top - this SKU adds 20 mm. Keep the stroke short relative to the cover: an over-long stroke on a compact body is a common mis-selection. Trailing S means a magnet is fitted for switch sensing; thread on this SKU is PT (G is available). Side-load capacity is not quoted here - ask us and we will check the datasheet.
Applications
Small-parts clamping
Clamp small components in fixtures where the no-rotating rod keeps the clamp pad square to the part, and the 6-direction fixing lets the cylinder bolt into tight clamp positions.
Jig positioning
Push parts against a jig stop with the adjustable stroke trimmed to the exact position needed, mounting several MKJ cylinders side by side on a crowded jig plate.
Parts stopper on conveyors
Extend across a conveyor lane to stop or divert small parts; the compact square body fixes from the top or side and the rod will not twist under the load.
FAQ
What does the code MKJ10X30-20S mean?
MKJ is the MK-family adjustable-stroke variant (double acting, no-rotating), 10 is the bore in mm, 30 is the base stroke in mm, -20 is the 20 mm adjustable range added on top, and the trailing S means a magnet is fitted. No trailing G means PT thread. At 0.5 MPa this bore gives about 39.3 N push.
Where can I mount this cylinder and how far can the stroke go?
The square body fixes from 6 directions - front, back, left, right, top and bottom - and cylinders can sit side by side to save space. Note the compact cover: keep the stroke short and sensible for the bore rather than stretching it. Exact dimensions, side-load limits and stroke tables come from the datasheet, which we confirm on request.
