Airtac MKJ Adjustable Cylinder MKJ10X35-10S
The AirTAC Airtac MKJ Adjustable Cylinder MKJ10X35-10S is a genuine MK multi-mount cylinder (adjustable stroke), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact. As an MK unit a fixed rod stops the piston rod rotating.
- TypeMulti-mount, adjustable stroke
- SeriesMK (no-rotating)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MKJ Adjustable Cylinder MKJ10X35-10S
The MKJ10X35-10S is a genuine AirTAC adjustable-stroke multi-mount cylinder with a compact square body that can be fixed from 6 directions - front, back, left, right, top and bottom - and mounted side by side to save space on manifolds and machine frames. Magnetic-switch slots are machined around the body, and the 10 mm bore delivers a theoretical push thrust of 39.3 N at 0.5 MPa in double-acting operation, suited to light clamping, positioning and stopping tasks. Cushioning is provided by a bumper, and the 35 mm stroke plus a 10 mm adjustable range lets you trim the final position without shimming.
This MK-family cylinder is no-rotating: a fixed rod, plate and brass bushing stop the piston rod from turning, so the load keeps its orientation through every cycle. As an MKJ variant it is double acting with an adjustable stroke, and this SKU includes the magnet (trailing S), ready for switch detection in the body slots. Ports are M5x0.8 with PT thread; operating pressure is 0.2-1.0 MPa with filtered air and a 1.5 MPa proof pressure. We confirm dimensions and sizing from the datasheet on request.
Airtac MKJ Adjustable Cylinder MKJ10X35-10S Technical Specifications
| Model | Airtac MKJ Adjustable Cylinder MKJ10X35-10S |
|---|---|
| Type | Multi-mount cylinder, adjustable stroke |
| Series | MK (no-rotating) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Choose the bore for thrust: at 0.5 MPa this 10 mm bore gives 39.3 N push and 33.0 N pull in double-acting operation, so size up if your load needs more. MK keeps the rod from rotating; if rotation is acceptable, the standard MD family is the alternative. Acting options include double (MK), single push (MSK), single pull (MTK), double rod (MKD) and adjustable stroke (MKJ, as here).
This model has a 35 mm stroke - the maximum for a 10 mm double-acting bore - plus a 10 mm adjustable range on top. Note the short cover: very long strokes on small bores are best avoided, so confirm suitability with us if you need more travel. Add the magnet with the S suffix (included here) and choose PT or G thread.
Applications
Conveyor gate stopper
Fix the body from the top or side of a conveyor frame to extend a stopper blade into the product path; the no-rotating rod keeps the blade square to the flow, and the 35 mm stroke with 10 mm adjustment sets the stop position precisely.
Small-parts clamp on fixtures
Bolt units side by side along a machining or assembly jig to clamp light parts with about 39.3 N push at 0.5 MPa; the 6-direction fixing lets the compact body mount where a tie-rod cylinder will not fit.
Indexing plate positioning
Use the adjustable 35+10 mm stroke to seat an indexing or escapement plate against a hard stop; the no-rotating plate and fixed rod stop the push face from twisting as it advances and retracts.
FAQ
What does the adjustable stroke on the MKJ10X35-10S mean in practice?
The 35 mm is the base stroke, and the MKJ variant adds a 10 mm adjustable range on top. You can shorten the effective stroke within that range to fine-tune the end position on your fixture instead of reworking the mounting. If you need a different range, the MKJ family is also offered with 20 mm and 30 mm adjustment.
How does the no-rotating feature affect mounting on a small machine?
The MK body fixes from 6 directions and the internal fixed rod, plate and bushing stop the rod from turning, so attached blades, plates or stops keep their orientation through every cycle. Because this bore has a short cover, avoid demanding an over-long stroke, and confirm side-load limits and exact dimensions from the datasheet before finalizing the layout.
