Airtac P-7V Blank Plate Repair Kit P-7V100M-R2
The AirTAC Airtac P-7V Blank Plate Repair Kit P-7V100M-R2 is a genuine blank plate kit for the 100M manifold. It seals an unused valve station so the base stays leak-tight, letting you buy a longer manifold now and fill the spare stations later.
- Part typeManifold blank plate kit
- Manifold100M
- Kit contentsOne blank plate and its screw
- Order codeR2
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac P-7V Blank Plate Repair Kit P-7V100M-R2
The P-7V100M-R2 is a blank plate kit for the 7V100M manifold base, the bar that carries 4V100 and 5V100 solenoid valves or 4A100 air pilot valves. Each kit contains one plate and one screw, and the plate closes a single empty station. Without it, an unfilled station is an open window on the common inlet: air would vent straight out of the spare position instead of reaching the valves further along the bank.
The kit exists to make spare capacity practical. Order a longer base than you need today, blank the stations you are not using yet, and the row stays leak-tight and tidy. When a new circuit is wanted, the plate is removed and a valve drops straight onto that station - no base swap, no re-piping the supply, no extra air drop to the machine.
Airtac P-7V Blank Plate Repair Kit P-7V100M-R2 Technical Specifications
| Model | Airtac P-7V Blank Plate Repair Kit P-7V100M-R2 |
|---|---|
| Part type | Manifold blank plate kit |
| Manifold series | 100M |
| Fits valve bodies | 4A100 air pilot and 4V100 / 5V100 solenoid |
| Kit contents | One blank plate and its screw |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Temperature | -20 to +70 °C |
| Replaces | The blank plate on any 100M station |
| Sold as | One kit per station |
This is a service part for the 100M manifold, not a valve. Check the manifold body size stamped on your base before ordering: a 100M blank plate does not fit a different body size.
Model Code: Airtac P-7V Blank Plate Repair Kit P-7V100M-R2
| P | Kit / service part. |
|---|---|
| 7V100M | For the 100M manifold of the 7V valve line. |
| R2 | R2 = blank plate kit (plate + screw). |
How a Manifold Bank Goes Together
- check One PT1/4 inlet feeds every station, so you run a single supply drop.
- check Each station takes one 100-body valve; the A and B work ports stay on the valve.
- check Exhausts collect in the base — silence the bank once instead of per valve.
- check Any station you are not using yet takes a P-100M-R2 blank plate.
- check Station seals are a serviceable part: P-100M-R1.
Where the Airtac P-7V Blank Plate Repair Kit P-7V100M-R2 Is Used
Electronics pick-and-place panel
A bench-mounted 7V100M bank driving vacuum and gripper circuits is ordered with two spare stations, each sealed by a P-7V100M-R2 plate until a third axis of small vacuum cups is added a year later.
Parcel sorting diverters
Conveyor divert cylinders on a logistics line run from 5V100 solenoids on a 7V100M base; a blanked station at the end of the row is the reserved home for a future reject-gate valve.
Small-parts feeding on packaging machines
A cartoning machine is built in stages, so its 7V100M base is bought long with two P-7V100M-R2 plates fitted; converting a station later is one screw and one valve, with the air supply untouched.
Is the Airtac P-7V Blank Plate Repair Kit P-7V100M-R2 the Right Part?
Check the prefix before ordering: the 7V100 in P-7V100M-R2 names the valve line, so this plate belongs on a 7V100M base for 100-body valves, not on a 200M, 300M or 400M bar or on any competitor's manifold. If the plate you are replacing sits under a valve rather than over an empty station, you have a leak between valve and base, and that is the job of the P-7V100M-R1 gasket kit instead.
Count the empty stations on your base and order one kit per station - a base with three blanked spares needs three plates. Keep one spare plate on the shelf if you blank stations in stages as a machine grows.
Quick checklist
- ✓ Valve body size (100) matches the base
- ✓ One kit covers one station
- ✓ Body size stamped on your manifold
Airtac P-7V Blank Plate Repair Kit P-7V100M-R2 FAQ
One kit seals exactly one station, so count the empty positions on your 7V100M base and order that number - three blanked spares means three kits. Each kit is a blank plate plus its screw, nothing more. When you later want the station live, remove the plate, seat the valve with a P-7V100M-R1 gasket kit, and the base feeds it from the common inlet.
Match the prefix. P-7V100M-R2 is sized for the 7V100M base, which carries 100-body valves: 4V100 and 5V100 solenoids or 4A100 air pilot valves, up to 16 stations with M5 or 1/8" station ports and a 1/4" common inlet. The base works with air filtered by a 40 um element from -20 to +70 C. If your bar is stamped 200M, 300M or 400M, this is not the plate for it.
