Airtac P-7V Blank Plate Repair Kit P-7V200M-R1
The AirTAC Airtac P-7V Blank Plate Repair Kit P-7V200M-R1 is a genuine gasket and screw kit for the 200M manifold. It replaces the station seals that sit between each valve and the base - the usual cure when a manifold starts leaking between stations.
- Part typeManifold gasket / seal kit
- Manifold200M
- Kit contentsManifold seal and screw
- Order codeR1
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac P-7V Blank Plate Repair Kit P-7V200M-R1
The P-7V200M-R1 is AirTAC's gasket and seal kit for the 200M manifold base used with the 7V200 valve series. The seal sits between each valve and the manifold face, and when it flattens or takes a set the result is a faint hiss at an idle station or a branch that will not hold pressure. Fitting a new seal cures that leak without touching the valves themselves.
Each kit contains exactly one station seal and one retaining screw, and one kit covers one station, so a full rebuild of a 16-station base needs 16 kits. The kit changes nothing about how the valves switch - it only restores the leak-tight joint between valve and base.
Airtac P-7V Blank Plate Repair Kit P-7V200M-R1 Technical Specifications
| Model | Airtac P-7V Blank Plate Repair Kit P-7V200M-R1 |
|---|---|
| Part type | Manifold gasket / seal kit |
| Manifold series | 200M |
| Fits valve bodies | 4A200 air pilot and 4V200 / 5V200 solenoid |
| Kit contents | Manifold seal and screw |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Temperature | -20 to +70 °C |
| Replaces | The gasket kit on any 200M station |
| Sold as | One kit per station |
This is a service part for the 200M manifold, not a valve. Check the manifold body size stamped on your base before ordering: a 200M gasket kit does not fit a different body size.
Model Code: Airtac P-7V Blank Plate Repair Kit P-7V200M-R1
| P | Kit / service part. |
|---|---|
| 7V200M | For the 200M manifold of the 7V valve line. |
| R1 | R1 = gasket / seal kit (seal + screw). |
How a Manifold Bank Goes Together
- check One PT1/4 inlet feeds every station, so you run a single supply drop.
- check Each station takes one 200-body valve; the A and B work ports stay on the valve.
- check Exhausts collect in the base — silence the bank once instead of per valve.
- check Any station you are not using yet takes a P-200M-R2 blank plate.
- check Station seals are a serviceable part: P-200M-R1.
Where the Airtac P-7V Blank Plate Repair Kit P-7V200M-R1 Is Used
Pick-and-place gripper panel
Robot end-of-arm valve banks on a 200 body manifold cannot tolerate a leaking idle station; renewing the valve-to-base seal with this kit removes the hiss without disturbing valve settings.
Bottling line actuator bank
Indexing and capping cylinders fed from a shared manifold lose speed when a station seal takes a set; one kit per affected station brings the bank back to full stroke.
Planned shutdown rebuilds
During an annual maintenance window a technician can lift each valve, fit a fresh seal and screw from one kit, and refit it - a per-station refresh that keeps a 16-station base leak-free.
Is the Airtac P-7V Blank Plate Repair Kit P-7V200M-R1 the Right Part?
Check the body size stamped on the manifold bar: this kit suits the 200 size on the 7V200 line and will not seal a 100, 300 or 400 base. Count the stations you are refreshing and order one kit per station rather than one for the whole bank. Because a 200M base accepts up to 16 stations, a bank-wide rebuild can take up to 16 kits, so order by station count, not by manifold length.
Quick checklist
- ✓ Valve body size (200) matches the base
- ✓ One kit covers one station
- ✓ Body size stamped on your manifold
Airtac P-7V Blank Plate Repair Kit P-7V200M-R1 FAQ
One kit services exactly one valve station, because it contains one station seal and one screw. Count the stations on your 200M base - up to 16 on the 200 body - and order one kit per station you are refreshing; a full 16-station rebuild needs 16 kits.
Match three things. R1 means gasket or seal kit rather than a blank plate. The 7V prefix means it is made for the manifold used with the 7V200 valve series. And the 200 is the body size, which must match the 200M base you have. It does not fit 100, 300 or 400 bases or another maker's manifold.
