Airtac TCM Triple Axis Cylinder TCM50X40-S
The AirTAC Airtac TCM Triple Axis Cylinder TCM50X40-S is a genuine JIS-standard guided cylinder with a Ø50mm bore and 40mm stroke on twin guide rods. Its integrated brass sliding bearing gives high radial-load and impact resistance — about double the horizontal impact tolerance of a plain cylinder, holding the tool square to ±0.05° of rotation without any external linear guide.
- BoreØ50 mm
- Stroke40 mm
- Port size1/4"
- BearingBrass sliding bearing
- Non-rotating±0.05°
- CushionRubber bumper
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TCM Triple Axis Cylinder TCM50X40-S
The AirTAC TCM50X40-S is a JIS-standard twin-rod guided cylinder featuring a robust brass sliding bearing. It integrates the drive piston and two guide rods into a single body, eliminating the need for an external linear rail while absorbing heavy side loads and torsion. This double-acting 50 mm bore unit generates 982 N of push force at 0.5 MPa, supported by a Ø20 mm piston rod on 1/4" ports.
Designed for harsh environments, the brass bearing shrugs off grit, coolant, and hard knocks, offering about twice the horizontal impact resistance of a plain cylinder where a steel-ball guide would jam. The twin-rod geometry maintains a non-rotating tolerance of ±0.05°, keeping a gripper or plate perfectly square under off-centre loads. Stroke termination is softened by fixed TPU rubber bumpers at each end, as this series uses no adjustable air cushion. A standard built-in magnet pairs with CS1 reed or DS1 electronic switches across four sensor slots, and PT thread ports are fitted as standard.
Airtac TCM Triple Axis Cylinder TCM50X40-S Technical Specifications
| Model | Airtac TCM Triple Axis Cylinder TCM50X40-S |
|---|---|
| Series | TCM JIS guided (twin-rod) cylinder |
| Bore size | Ø50 mm |
| Stroke | 40 mm |
| Acting type | Double acting |
| Bearing | Brass sliding bearing |
| Port size | 1/4" |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Non-rotating tolerance | ±0.05° (retracted) |
| Cushion | Rubber bumper |
| Max std stroke | Up to 250 mm |
Specifications follow the official AirTAC TCL/TCM series datasheet (JIS standard). Confirm against the product label before installation. Thread options: PT (blank) / G / NPT. Every TC model ships with a built-in magnet for sensor switches.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max | 200 kgf | |
Force is set by the bore and piston rod (Ø20 mm); the twin guide rods carry side load and torque, not thrust. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac TCM Triple Axis Cylinder TCM50X40-S
| TC | Tri-rod (guided, twin-rod) cylinder, double acting. |
|---|---|
| M | Bearing: Brass sliding bearing (M = brass sliding). |
| 50 | Bore size in mm. |
| ×40 | Stroke length in mm. |
| S | Built-in magnet (standard on TC) for a magnetic sensor switch. |
Sister type: TCL50X40 (steel-ball linear bearing, lower friction & higher precision). Thread codes: blank = PT · G · T = NPT.
Where the Airtac TCM Triple Axis Cylinder TCM50X40-S Is Used
Heavy Pallet Stop
With 982 N of thrust at 0.5 MPa, this cylinder halts heavy pallets on a dusty transfer line, where the brass sliding bearing tolerates abrasive grit that would destroy a ball guide.
Off-Centre Gripper Slide
The ±0.05° non-rotating tolerance keeps a heavy-duty gripper square while lifting asymmetric parts, absorbing the torsional load without needing a separate external guide rail.
Foundry Pattern Push
In a hot, contaminant-filled foundry, the brass bearing shrugs off sand and scale while delivering 1374 N of push at 0.7 MPa to position heavy mould patterns reliably.
Is the Airtac TCM Triple Axis Cylinder TCM50X40-S the Right Cylinder?
When sizing this model, consider stepping down to a Ø40 bore for roughly 628 N of push at 0.5 MPa, or moving up to a Ø63 bore for 1559 N if your application requires greater thrust. Choose the sister TCL series with its steel-ball linear bearing instead if your task demands low-friction precision or vertical high-load handling rather than impact tolerance.
Note that the TCM50X40-S will not hold its load vertically if air pressure drops or the valve is centered; the guide resists rotation but not gravity, so fit an external rod lock or pilot-operated check valve for fail-safe positioning. This 40 mm stroke is a standard length, and the unit includes the standard S magnet and PT port threads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Side load / torque the guide must carry
- ✓ TCL (precision, low friction) vs TCM (impact, radial load)
- ✓ Stroke & mounting face (top / bottom / rear)
- ✓ Port/thread type (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check The guide unit takes side load & torque — but do not exceed the max safe load/torque for your stroke.
- check Mount from the top, bottom (screw or T-slot) or rear face; use the precision locating holes.
- check Do not disassemble the fixing block or guide unit — factory-set precision.
- check Fit CS1 / DS1 magnetic switches in the four sensor slots as needed.
Airtac TCM Triple Axis Cylinder TCM50X40-S FAQ
This 50 mm bore double-acting cylinder provides 982 N of push and 825 N of pull at 0.5 MPa, 1374 N of push at 0.7 MPa, with a theoretical maximum force of 200 kgf.
A moulded rubber bumper absorbs the stop at both ends, with no air-cushion screw to set. This fixed TPU bumper softens the impact but cannot be adjusted like a standard pneumatic cushion.
