Airtac TCM Triple Axis Cylinder TCM50X60-S
The AirTAC Airtac TCM Triple Axis Cylinder TCM50X60-S is a genuine JIS-standard guided cylinder with a Ø50mm bore and 60mm stroke on twin guide rods. Its integrated brass sliding bearing gives high radial-load and impact resistance — about double the horizontal impact tolerance of a plain cylinder, holding the tool square to ±0.05° of rotation without any external linear guide.
- BoreØ50 mm
- Stroke60 mm
- Port size1/4"
- BearingBrass sliding bearing
- Non-rotating±0.05°
- CushionRubber bumper
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TCM Triple Axis Cylinder TCM50X60-S
The AirTAC TCM50X60-S is a JIS double-acting twin-rod guided cylinder featuring a robust brass sliding bearing. A central drive piston runs between two guide rods in a single integrated body, eliminating the need for an external linear rail while delivering 982 N of push and 825 N of pull at 0.5 MPa. With a 50 mm bore and 60 mm stroke, it generates up to 1374 N at 0.7 MPa, making it well suited for heavy-duty positioning tasks.
This model excels in harsh environments where contamination would destroy a steel-ball guide. The brass bearing shrugs off dust, grit, and coolant while providing roughly double the horizontal impact resistance of a conventional plain cylinder. Anti-rotation precision is held to ±0.05°, keeping grippers or plates perfectly square under offset loads. The unit feeds via 1/4" ports and uses a Ø20 mm piston rod. Stroke ends are damped by fixed elastomer pads rather than an adjustable cushion, and a standard built-in magnet enables position sensing.
Airtac TCM Triple Axis Cylinder TCM50X60-S Technical Specifications
| Model | Airtac TCM Triple Axis Cylinder TCM50X60-S |
|---|---|
| Series | TCM JIS guided (twin-rod) cylinder |
| Bore size | Ø50 mm |
| Stroke | 60 mm |
| Acting type | Double acting |
| Bearing | Brass sliding bearing |
| Port size | 1/4" |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Non-rotating tolerance | ±0.05° (retracted) |
| Cushion | Rubber bumper |
| Max std stroke | Up to 250 mm |
Specifications follow the official AirTAC TCL/TCM series datasheet (JIS standard). Confirm against the product label before installation. Thread options: PT (blank) / G / NPT. Every TC model ships with a built-in magnet for sensor switches.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max | 200 kgf | |
Force is set by the bore and piston rod (Ø20 mm); the twin guide rods carry side load and torque, not thrust. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac TCM Triple Axis Cylinder TCM50X60-S
| TC | Tri-rod (guided, twin-rod) cylinder, double acting. |
|---|---|
| M | Bearing: Brass sliding bearing (M = brass sliding). |
| 50 | Bore size in mm. |
| ×60 | Stroke length in mm. |
| S | Built-in magnet (standard on TC) for a magnetic sensor switch. |
Sister type: TCL50X60 (steel-ball linear bearing, lower friction & higher precision). Thread codes: blank = PT · G · T = NPT.
Where the Airtac TCM Triple Axis Cylinder TCM50X60-S Is Used
Foundry Sand Mold Press
Tolerates extreme grit and heat while compacting sand molds. The brass sliding bearing resists contamination where a ball guide would jam, delivering 982 N of thrust at 0.5 MPa without faltering.
Heavy Pallet Stopper
Halts loaded pallets on a dusty transfer line. The twin guide rods absorb the severe radial impact, and the ±0.05° non-rotating tolerance keeps the stopping blade perfectly aligned.
Weld Cell Clamp Slide
Positions a heavy off-centre gripper in a robotic weld cell. Shrugs off weld spatter and coolant spray while providing 1374 N of clamping force at 0.7 MPa.
Is the Airtac TCM Triple Axis Cylinder TCM50X60-S the Right Cylinder?
Selecting this 50 mm bore provides 982 N of thrust at 0.5 MPa. If your application requires less force, stepping down to the Ø40 bore yields about 628 N of push, whereas moving up to the Ø63 bore provides 1559 N for heavier demands. This cylinder uses a 1/4" port and a Ø20 mm rod, with PT threaded ports by default and a standard built-in magnet (S).
Consider the sibling TCL series with its steel-ball linear bearing instead if your task demands low-friction movement, extreme vertical lifting, or high-precision positioning. Remember that the TCM brass sliding bearing is purpose-built for dirty, impacting, and heavy-radial-load duty. Furthermore, the guide prevents rotation but will not stop the rod from drifting downward if air pressure is lost or the valve is centered; install an external rod lock or pilot-operated check valve for fail-safe load holding.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Side load / torque the guide must carry
- ✓ TCL (precision, low friction) vs TCM (impact, radial load)
- ✓ Stroke & mounting face (top / bottom / rear)
- ✓ Port/thread type (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check The guide unit takes side load & torque — but do not exceed the max safe load/torque for your stroke.
- check Mount from the top, bottom (screw or T-slot) or rear face; use the precision locating holes.
- check Do not disassemble the fixing block or guide unit — factory-set precision.
- check Fit CS1 / DS1 magnetic switches in the four sensor slots as needed.
Airtac TCM Triple Axis Cylinder TCM50X60-S FAQ
At 0.5 MPa, this 50 mm bore cylinder provides 982 N of push and 825 N of pull. At its maximum operating pressure of 1.0 MPa, it generates a theoretical maximum force of 200 kgf. The push force at 0.7 MPa is 1374 N.
There is no adjustable air cushion; each end of stroke relies on a fixed rubber TPU bumper to soften the impact. For position feedback, the standard built-in magnet works with AirTAC CS1 reed switches or DS1 electronic sensors fitted into any of the four body slots.
