Airtac TCM Triple Axis Cylinder TCM50X90-S
The AirTAC Airtac TCM Triple Axis Cylinder TCM50X90-S is a genuine JIS-standard guided cylinder with a Ø50mm bore and 90mm stroke on twin guide rods. Its integrated brass sliding bearing gives high radial-load and impact resistance — about double the horizontal impact tolerance of a plain cylinder, holding the tool square to ±0.05° of rotation without any external linear guide.
- BoreØ50 mm
- Stroke90 mm
- Port size1/4"
- BearingBrass sliding bearing
- Non-rotating±0.05°
- CushionRubber bumper
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TCM Triple Axis Cylinder TCM50X90-S
The AirTAC TCM50X90-S is a JIS-standard twin-rod guided cylinder with a brass sliding bearing. A central Ø20 piston rod drives the load while two flanking guide rods absorb radial force and torque, eliminating the need for an external linear rail. Delivering 982 N of push at 0.5 MPa, this double-acting unit handles heavy side loads with a ±0.05° non-rotating tolerance, keeping wide grippers or plates perfectly square.
Built for harsh environments, the brass sliding bearing shrugs off weld spatter, coolant, and grit where a steel-ball guide would jam, offering roughly twice the horizontal impact resistance of a plain cylinder. The 1/4" PT ports can be plumbed from the upper face or side, and a moulded rubber bumper absorbs the stop at both ends, with no air-cushion screw to set. A standard built-in magnet pairs with CS1 reed or DS1 electronic switches in the four body slots.
Airtac TCM Triple Axis Cylinder TCM50X90-S Technical Specifications
| Model | Airtac TCM Triple Axis Cylinder TCM50X90-S |
|---|---|
| Series | TCM JIS guided (twin-rod) cylinder |
| Bore size | Ø50 mm |
| Stroke | 90 mm |
| Acting type | Double acting |
| Bearing | Brass sliding bearing |
| Port size | 1/4" |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Non-rotating tolerance | ±0.05° (retracted) |
| Cushion | Rubber bumper |
| Max std stroke | Up to 250 mm |
Specifications follow the official AirTAC TCL/TCM series datasheet (JIS standard). Confirm against the product label before installation. Thread options: PT (blank) / G / NPT. Every TC model ships with a built-in magnet for sensor switches.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max | 200 kgf | |
Force is set by the bore and piston rod (Ø20 mm); the twin guide rods carry side load and torque, not thrust. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac TCM Triple Axis Cylinder TCM50X90-S
| TC | Tri-rod (guided, twin-rod) cylinder, double acting. |
|---|---|
| M | Bearing: Brass sliding bearing (M = brass sliding). |
| 50 | Bore size in mm. |
| ×90 | Stroke length in mm. |
| S | Built-in magnet (standard on TC) for a magnetic sensor switch. |
Sister type: TCL50X90 (steel-ball linear bearing, lower friction & higher precision). Thread codes: blank = PT · G · T = NPT.
Where the Airtac TCM Triple Axis Cylinder TCM50X90-S Is Used
Pallet Transfer Line Stop
Halting heavy pallets moving down a dusty conveyor, the brass sliding bearing tolerates abrasive grit while delivering 982 N of stopping force at 0.5 MPa without needing a separate shock absorber.
Off-Centre Gripper Slide
Lifting an asymmetric part, the twin guide rods maintain a ±0.05° non-rotating tolerance, keeping the wide gripper plate square and absorbing the induced torsional load.
Weld-Cell Clamp Positioner
Positioning a heavy weld clamp in a dirty cell, the brass sleeve resists spatter and contamination where a ball bearing would jam, while providing 1374 N of clamping thrust at 0.7 MPa.
Is the Airtac TCM Triple Axis Cylinder TCM50X90-S the Right Cylinder?
If 982 N of thrust is more than your space allows, stepping down to the Ø40 bore provides about 628 N of push at 0.5 MPa. For heavier gating or pressing demands, moving up to the Ø63 bore yields 1559 N. Both neighbours use the same 30-500 mm/s speed range and 0.15-1.0 MPa operating pressure.
Choose the sister TCL series with its steel-ball linear bearing only if your task demands low-friction precision or vertical high-load handling. Note that this TCM does not hold its load if air pressure is lost; the rod drifts, so fit an external rod lock or pilot-operated check valve for fail-safe positioning. This 90 mm stroke is a standard length, and the built-in S magnet is standard across the range.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Side load / torque the guide must carry
- ✓ TCL (precision, low friction) vs TCM (impact, radial load)
- ✓ Stroke & mounting face (top / bottom / rear)
- ✓ Port/thread type (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check The guide unit takes side load & torque — but do not exceed the max safe load/torque for your stroke.
- check Mount from the top, bottom (screw or T-slot) or rear face; use the precision locating holes.
- check Do not disassemble the fixing block or guide unit — factory-set precision.
- check Fit CS1 / DS1 magnetic switches in the four sensor slots as needed.
Airtac TCM Triple Axis Cylinder TCM50X90-S FAQ
At 0.5 MPa, the Ø50 bore delivers 982 N of push and 825 N of pull. At the maximum 0.7 MPa operating pressure, the push force reaches 1374 N. The theoretical maximum force is 200 kgf.
The TCM uses an impact-tolerant brass sliding bearing for dirty, heavy-radial duty, whereas the TCL uses a low-friction steel-ball linear bearing for high-precision vertical work. This unit ships with a standard built-in magnet compatible with AirTAC CS1 reed and DS1 electronic switches in any of the four body slots.
