Airtac TCM Triple Axis Cylinder TCM63X60-S
The AirTAC Airtac TCM Triple Axis Cylinder TCM63X60-S is a genuine JIS-standard guided cylinder with a Ø63mm bore and 60mm stroke on twin guide rods. Its integrated brass sliding bearing gives high radial-load and impact resistance — about double the horizontal impact tolerance of a plain cylinder, holding the tool square to ±0.05° of rotation without any external linear guide.
- BoreØ63 mm
- Stroke60 mm
- Port size1/4"
- BearingBrass sliding bearing
- Non-rotating±0.05°
- CushionRubber bumper
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TCM Triple Axis Cylinder TCM63X60-S
The AirTAC TCM63X60-S is a JIS-standard twin-rod guided cylinder with a brass sliding bearing. It integrates the drive piston and two guide rods into one body, eliminating the need for an external linear rail. This double-acting actuator delivers 1559 N of push and 1402 N of pull at 0.5 MPa, driven by a Ø20 mm piston rod on 1/4" ports. With a non-rotating tolerance of ±0.05°, it keeps grippers and plates square under off-centre loads.
The brass sliding bearing shrugs off dust, grit, and hard knocks, offering about twice the horizontal impact resistance of a plain cylinder. Stroke ends are damped by fixed elastomer pads rather than an adjustable cushion. Ports are PT by default, and the standard built-in magnet works with CS1 reed or DS1 electronic switches in the four body slots.
Airtac TCM Triple Axis Cylinder TCM63X60-S Technical Specifications
| Model | Airtac TCM Triple Axis Cylinder TCM63X60-S |
|---|---|
| Series | TCM JIS guided (twin-rod) cylinder |
| Bore size | Ø63 mm |
| Stroke | 60 mm |
| Acting type | Double acting |
| Bearing | Brass sliding bearing |
| Port size | 1/4" |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Non-rotating tolerance | ±0.05° (retracted) |
| Cushion | Rubber bumper |
| Max std stroke | Up to 250 mm |
Specifications follow the official AirTAC TCL/TCM series datasheet (JIS standard). Confirm against the product label before installation. Thread options: PT (blank) / G / NPT. Every TC model ships with a built-in magnet for sensor switches.
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max | 318 kgf | |
Force is set by the bore and piston rod (Ø20 mm); the twin guide rods carry side load and torque, not thrust. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac TCM Triple Axis Cylinder TCM63X60-S
| TC | Tri-rod (guided, twin-rod) cylinder, double acting. |
|---|---|
| M | Bearing: Brass sliding bearing (M = brass sliding). |
| 63 | Bore size in mm. |
| ×60 | Stroke length in mm. |
| S | Built-in magnet (standard on TC) for a magnetic sensor switch. |
Sister type: TCL63X60 (steel-ball linear bearing, lower friction & higher precision). Thread codes: blank = PT · G · T = NPT.
Where the Airtac TCM Triple Axis Cylinder TCM63X60-S Is Used
Pallet Transfer Line Stop
Halting heavy inbound pallets on a dusty conveyor is easy for the brass sliding bearing, which tolerates grit and impact while the 1559 N thrust at 0.5 MPa stops the load firmly.
Foundry Sand-Mould Press
Compressing sand moulds exposes the actuator to harsh debris; the TCM guide shrugs off contamination where a ball bearing would jam, while delivering 2182 N of push at 0.7 MPa.
Off-Centre Gripper Slide
Moving an offset gripper over 60 mm keeps the tool square thanks to the ±0.05° non-rotating tolerance, with the twin guide rods absorbing the torsional moment.
Is the Airtac TCM Triple Axis Cylinder TCM63X60-S the Right Cylinder?
This Ø63 bore provides 1559 N of thrust at 0.5 MPa. If your pushing requirement is lighter, the Ø50 model offers 982 N of push at 0.5 MPa. For heavier radial duty, stepping up to the Ø80 model yields 2513 N of thrust at 0.5 MPa. Choose the sister TCL series with its steel-ball linear bearing instead if your application demands low friction and high vertical precision.
To replace this unit, match the 63 mm bore, 60 mm stroke, 1/4" port size, and PT thread form. Remember that a TCM does not hold its load if air pressure is lost or the valve is centred, as the rod drifts; the guide resists rotation, not gravity. For a fail-safe hold, install an external rod lock or a pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Side load / torque the guide must carry
- ✓ TCL (precision, low friction) vs TCM (impact, radial load)
- ✓ Stroke & mounting face (top / bottom / rear)
- ✓ Port/thread type (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check The guide unit takes side load & torque — but do not exceed the max safe load/torque for your stroke.
- check Mount from the top, bottom (screw or T-slot) or rear face; use the precision locating holes.
- check Do not disassemble the fixing block or guide unit — factory-set precision.
- check Fit CS1 / DS1 magnetic switches in the four sensor slots as needed.
Airtac TCM Triple Axis Cylinder TCM63X60-S FAQ
At 0.5 MPa, this 63 mm bore cylinder generates 1559 N of push and 1402 N of pull. At 0.7 MPa, the push force is 2182 N. The maximum theoretical force is 318 kgf.
No, there is no air-cushion screw to set. A moulded rubber bumper absorbs the stop at both ends of the stroke. The cylinder relies on this fixed elastomer pad for end-of-travel damping.
