Airtac 5A Pneumatic Control Valve 5A21008
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A21008 Pneumatic Control Valve Specifications
- Model: 5A21008
- Type: 5-port 2-position (5/2-way) pneumatic pilot-operated valve
- Port size: PT1/4 (G1/4 optional)
- Thread standard: ISO G/ISO PT/NPT (customizable)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 850 NL/min (ANR)
- Actuation type: Air pilot (requires 0.3 MPa minimum pilot pressure)
- Response time: ≤ 30 ms (at 0.5 MPa)
- Seal material: HNBR rubber (standard), optional FKM for high temp
- Temperature range: -20℃ to 80℃ (extended to 120℃ with FKM seals)
- Weight: 520g ±5% (without accessories)
- Dimensions: 80mm(L) × 40mm(W) × 60mm(H)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤0.02 MPa
- Leakage: ≤3 bubbles/min (per ISO 6953-2)
- Cycle life: ≥10 million operations
High-flow directional control valve with symmetrical internal flow paths, optimized for bidirectional cylinder control. Features dual-pressure capability and low pilot consumption design. The aluminum alloy body with hard anodized finish resists chemical corrosion. Requires 5μm filtered/dried air with ISO 8573-1:2010 Class 3.2.4 air quality.
- Industrial automation sequencing systems
- Plastic injection molding machine clamp control
- Automotive assembly line tooling actuators
- Textile machinery tension control systems
- Palletizing robot end-effector controls
Installation guidelines:
Mount with manifold base (e.g., 5M-210 series) for optimal performance.
Maintain 15mm clearance below valve for heat dissipation. Lubricate with ISO VG32
turbine oil if air line lubrication is used. Avoid side-loading during tubing connection.
| Property | Property Value |
|---|---|
| sku | 5A21008 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
