Airtac 5A Pneumatic Control Valve 5A22008
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A22008 Pneumatic Control Valve Technical Specifications
- Model: 5A220-08 (5A22008)
- Type: 5/2-way single solenoid spring return
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage options: DC12V, DC24V, AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.48 kg ±2%
- Dimensions: 56mm(L) × 40mm(W) × 90mm(H)
- Flow capacity: 850 L/min (Cv=1.2)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with reinforced polyamide body for industrial durability. Features manual override button for system debugging and emergency operation. Designed for ISO 15407-1 compliance with double-walled coil protection against voltage spikes. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 quality.
- Plastic injection molding machine cylinder control
- Automated assembly line actuator sequencing
- CNC machine tool clamping systems
- Material handling pneumatic circuits
- Textile machinery air flow management
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 20mm clearance below valve for exhaust airflow.
Lubricate using ISO VG32 turbine oil if air line lubrication is absent.
| Property | Property Value |
|---|---|
| sku | 5A22008 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
