Airtac 6A Pneumatic Control Valve 6A0530PM5
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A0530PM5 Pneumatic Control Valve Specifications
- Model: 6A0530PM5
- Type: 5-port 3-position (Mid-block center)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Control method: Air pilot operated (single/double available)
- Weight: 320g ±5g
- Dimensions: 78mm(L) × 25mm(W) × 45mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with wear-resistant coating
- Temperature range: -10℃ to 80℃ (with silicone seals optional for -20℃)
- Flow rate: 850 L/min (ANR) at 0.5MPa
- Response time: ≤80ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement 9mm)
High-flow directional control valve with precision-machined aluminum body and anti-vibration design. Features dual-position memory function and low pilot pressure requirement (≥0.25MPa). Optimized for high-cycle applications with 10 million+ service life rating. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers and palletizers
- Foundry equipment with high particulate environments
- Bottle filling/packaging machinery
Installation note:
Mount with vibration-damping brackets in high-shock environments.
Lubricate pilot ports with ISO VG32 pneumatic oil monthly in continuous operation.
Avoid mounting near electromagnetic interference sources (≥30cm clearance from motors).
- Seal replacement: 5 million cycles or 2 years (whichever first)
- Pressure test: Recommended every 6 months for critical systems
- Cleaning: Ultrasonic cleaning permissible (max 40kHz, 60℃)
| Property | Property Value |
|---|---|
| sku | 6A0530PM5 |
| Port Size | M5 |
