Airtac 6HV Manifold Solenoid Valve 6HV0500M15F
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0500M15F Modular Solenoid Valve Specifications
- Model: 6HV0500M15F
- Series: 6HV Modular Stackable Design
- Operation type: 5/2-way, double solenoid (bi-stable)
- Port configuration: 1/2" NPT (G1/2 optional)
- Effective bore diameter: 12mm
- Operating pressure range: 0.1-1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤20ms (actuation), ≤15ms (release)
- Flow capacity: 1200 l/min (ANR) at 0.5MPa
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Weight: 850g ±3% (excluding connectors)
- Dimensions: 80mm(W) × 72mm(H) × 135mm(L)
- Port alignment: ISO 5599-1 standard interface
- Power consumption: 4.5W (DC), 5.2VA (AC)
- Protection class: IP65 (dust-tight & water jet resistant)
- Mounting orientation: Any (horizontal/vertical)
High-flow modular solenoid valve engineered for industrial automation systems requiring multi-valve configurations. Features dual manual override buttons (front/rear) for emergency operation and status confirmation. The anodized aluminum body with hardened brass cores ensures durability in high-cycle applications. Compatible with ISO mounting systems for flexible manifold assembly.
- Automated assembly line clamping mechanisms
- Plastic injection molding machine actuators
- CNC machine tool pneumatic circuits
- Palletizing robot end-effector controls
- Industrial dryer valve manifolds
Maintenance protocol:
Use ISO VG32 turbine oil (1-2 drops per port) monthly in dry environments.
Maximum stacking: 12 valves per manifold. Maintain 20mm clearance between
stacked modules for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 6HV0500M15F |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
