Airtac 6HV Manifold Solenoid Valve 6HV0500M18F
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0500M18F Modular Solenoid Valve Specifications
- Model: 6HV0500M18F
- Type: 5/2-way monostable (modular stackable design)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 600g ±5% (excluding accessories)
- Dimensions: 100mm(L) × 30mm(W) × 50mm(H)
- Body material: Brass (electroless nickel plated)
- Seal material: HNBR (hydrogenated nitrile) for high temperature resistance
- Temperature range: -5℃ to 80℃ (with intermittent peaks to 120℃)
- Flow capacity: 750 NL/min (ANR standard)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Manual override: Built-in emergency push button
- Mounting pitch: 18mm (stackable design)
High-density modular valve optimized for multi-station pneumatic systems, featuring gold-plated electrical contacts for reliable signal transmission. The F-series variant includes enhanced dust resistance with labyrinth seals in spool structure. Requires 5μm filtered air with oil mist (ISO 8573-1 class 3).
- Multi-axis robotic end effector control
- Pharmaceutical blister packaging machines
- Automotive welding fixture sequencing
- Bottle cap sorting systems
- Semiconductor wafer handling robots
Installation note:
Maintain 2-3mm clearance between stacked valves for heat dissipation.
Use M3×8 stainless steel screws (1.2-1.5N·m torque) for manifold mounting.
Lubricate seals with PAG oil during maintenance.
